4K Wall Mount IR Multi Touch Screen LCD Monitor 32 to 98 Inch Resolution 3840 * 2160

    • 4K Wall Mount IR Multi Touch Screen LCD Monitor 32 to 98 Inch Resolution 3840 * 2160
    • 4K Wall Mount IR Multi Touch Screen LCD Monitor 32 to 98 Inch Resolution 3840 * 2160
    • 4K Wall Mount IR Multi Touch Screen LCD Monitor 32 to 98 Inch Resolution 3840 * 2160
    • 4K Wall Mount IR Multi Touch Screen LCD Monitor 32 to 98 Inch Resolution 3840 * 2160
  • 4K Wall Mount IR Multi Touch Screen LCD Monitor 32 to 98 Inch Resolution 3840 * 2160

    Product Details:

    Place of Origin: China
    Brand Name: ZXT
    Certification: CE,FCC,ROHS
    Model Number: ZXT-WTM430A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Piece
    Price: Negotiation
    Packaging Details: Inner 4CM PE foam, Middle export carton box, Outer export wooden box
    Delivery Time: 7-10 workdays
    Payment Terms: T/T, Western Union,Paypal
    Supply Ability: 5,000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Touch Screen Monitor Sizes: 32'' To 98''
    Resolution: 4K 3840*2160 Type: Wall Mount
    Touch Screen: IR Touch Screen Touch Points: 6 To 10 Points

    4K Wall Mount 32" 37" 40" 42" 43" 46" 47" 49" 50" 52" 55" 60" 75" 80"98" IR Multi Touch Screen Monitor



    ZXT touch screen monitor are e-LED LCD flat panel displays that range in size to accommodate any collaboration environment and include a premium interactive experience. Their stunning visuals offer the richest experience to create, share and interact with digital content.

    Beautiful to look at. Impressive to work with. Our Interactive Flat Panels let you wow your audience with digital content that shines and ideas they’ll want to get their hands on.



    ZXTBoard interactive flat panel hardware features:

    • Board writing smoothly and fluently ,with high precision;
    • No light spots, to protect user’s eyes;
    • the ZXTBoard could be used also as a TV to display.
    • All size of board can satisfy different requirement of customers.
    • The infrared sensor is separated from the TV, be convenient for after-sale to repair quickly
    • 4mm thickness tempered glass, Effectively protect the screen.

    ZXTBoard interactive flat panel software features:

    • Free upgrade for life;
    • Offering free resource download website;
    • Supports diverse resource database self-defined by common format files, no limit to the number of resource;
    • Marking play-status of Microsoft PowerPoint;
    • Catching and marking any desktop contents (files can be printed )
    • Audio , video recording and playback function
    • Users can expand the application functionality themselves
    • One key switch between left mouse button and right mouse button.
    • Supporting to insert images, animation, video and other files
    • Supporting to self-defined shortcut button function.



    Product Specification:

    Interactive Flat Panel
    Size 55 Inch 65 Inch 70 Inch 84 Inch
    Aspect Ratio 16:9
    Light LED
    View Angle 178°
    Response Rate 8ms
    Resolution 1920 x 1080 3840 x 2160
    Contrast Ratio 4000:1 1600:1
    Color 16.7M 10bit(1.06Billon)
    Input Port HD*2,VGA*1,PC-AUDIO*1,YPBPR*1,YPBPR-AUDID*1,TV-IN*1,AV-IN*1,TV-MIC*1 HD*3,VGA*1,PC-AUDIO*1,YPBPR*1,CVBS*1,CVBS Audio*1
    Output Port AV-OUT*1,TV-AUDIO*1 COAX*1,EARPHONE*1
    Communication Port USB(TV)*2,USB(PC)*1,USB(TOUCH)*1,RS232*1

    USB(TV)*2,USB(PC)*1,

    USB(TOUCH)*1,RS232*1

    Brightness 350cd/m² 360cd/m² 400cd/m² 350 cd/m2
    Power consumption ≤190W ≤240W ≤320W ≤500W
    Standby consumption ≤1W ≤1W ≤1W ≤2W
    Power Supply 100 V ~ 240 V, 50-60 Hz
    Speaker 10W * 2
    Working Temperature 0°C ~ 50°C
    Storage Temperature -20°C ~ 60°C
    Product Size 1290.0 * 782.6 * 65.0 mm 1536 * 931 * 80 mm 1636.90 * 981.45 * 92.50 mm 1965.2 * 1164.2 * 91.12mm
    Active Area 1209.6mm x 680.4mm 1428.48 x 803.52mm 1549.44 x 871.56mm 1860.48 mm×1046.52 mm
    Net Weight 45Kg 72 Kg 75.5Kg 146Kg
    Gross Weight 53.5Kg 95.5Kg 207Kg



    Infrared touch panel specification:

    Touch Principle Infrared Power Supply USB Power
    Writing Tools Finger, Pen or other no transparent object Response rate <20ms
    Drive Mode No need driver Touch Precision ±2mm
    Communication Port USB2.0 Supported OS Windows 7 /Windows XP/Vista/Linux/Mac/Android/Wince
    Resolution 8192*8192 Tempered Glass Thickness 4mm



    OPC Computer specification(Optional):

    Structure OPS Computer CPU Intel I3 or I5
    MotherBoard H61 Chipsets Memory 4GB or More
    Hard Disk 500GB More WIFI Yes
