35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display

35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display

35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display
35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display
35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display
Product Details:
Place of Origin: China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC/ERP Energy Label
Model Number: ZXTLCD-BAR355BJ
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Machine body appearance wrapped in pearl carton firstly, packed in carton
Delivery Time: 3~5 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 300pcs per month
Contact Now
Detailed Product Description
Screen Size: 35.5 Inch Resolution: 1920(V) X 372(H)
Brightness: 400cd/m2 Contrast Ratio: 1000:1
Backlight Type: WLED Active Display Area: 885.6(H) X 172(V)mm
High Light:

WLED Stretched Bar Lcd Panel

,

35.5" Stretched Bar Lcd Panel

,

60W Stretched Bar LCD Monitor

35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display



Features:



1), Supports that the advertising players in the same group can be played synchronously and the synchronization interval is less than 500ms.



2), Support remote setting of advertising player properties, control of advertising player volume, rotation angle, time zone, etc.



3), Support real-time management and release on mobile phone, iPad and PC Support remote monitoring of the network status, system status and hardware status of the advertising player, and monitor the content of the advertising player.



4), Support the needs of multiple forms of rolling subtitles and bullet screens, the font, size and content of subtitles and bullet screens can be edited.







You can either play the bar as a single screen, support USB plug and play, or you can use it as a video wall, which is quite the talking point.





The specification
Model No Product model ZXTLCD-BAR355BJ
LCD Screen Panel Screen size 35.5" LCD Panel
Active display area 885.6(H) X 172(V)mm
Resolution 1920(V) X 372(H)
Brightness 400cd/m2
Contrast ratio 1000:1
Display color 16.7M
Backlight type WLED
Viewing angles

178°(H) X 178°(V)

Response time 9ms
Lifespan 50000 hours
Main board CPU Rockchip PX30 Quad core ARM Cotex-A35
RAM 1G DDR3(1 G/2G for optional )
ROM 8G EMMC(8G/16G/32G/64GEMMC for optional)
Memory extension TF Card extension with the highest support for 64GB
System Android 8.1
Internet Support 2.4G WIFI connection
RTC real time clock Support timing on / off function
Interfaces 1xTF card slot
1*micro USB(OTG)
1*Type-c(DC 12V input,Need to match with our company's special adapter for power supply)
External function optional 4G module
8Ω1WX1 speaker
Support special requirements customization
machine specification Operating voltage 100-240V(50/60Hz)
Power consumption ≤60W
Product size 733.5(H)X235(V)X51(D)mm
Installation wall-mounted
Apperance material Metal shell
Net weight ≤6KG
Surface treatment Black metal paint
Environmental Storage Environment Temperature:-20℃~60℃
Humidity:5%~95%
Atmospheric Pressure:86kPa~104kPa
Working Environment Temperature:0℃~45℃
Humidity:10%~85%
Atmospheric Pressure:86KPa~104KPa
Packing list Bar lcd display 1pcs
Power Cable 1Pcs
Support special requirements customization





35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display 0



Basically, think of these stretched bar LCD displays as long and thin miniature TVs that advertise certain products and services.

35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display 1



These bars are proving to be very popular, despite being fairly new, and have been hailed as the next best thing in advertising.



35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display 2



35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display 3





Physical Photo for reference



35.5 inch Stretched Bar Lcd Display Ultrawide Monitor Ultra-Wide Stretched Bar Type LCD Display 4



Please send us a inquiry if you want to know much more
