Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC/ERP Energy Label |
| Model Number: | ZXTLCD-LD550KC |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| ANT In (IEC Terrestrial/cable): | 1 Piece | OSD Language: | Multi Language Optiona |
|---|---|---|---|
| Use: | Advertising Publish, Retail Store, Shopping Mall, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Restaurant & Hotel Supplies, Medical Treatment | Specification: | Digital Poster, Kiosk |
| Brightness: | Max 1000nit, 1500nit | Installation Type: | Floorstanding |
| Warranty: | One Year For Free, Three Years For Cost Maintainence | Protection Glass: | 6mm AR Safe Glass |
| Panel Brand: | LG / BOE | Viewing Angle: | 178°/178° |
| Keywords: | Waterproof Outdoor Digital Signage |
With the acceleration of the digitalization process, outdoor advertising has become increasingly diverse. Traditional forms of promotion such as paper-based ads and lightboxes can no longer satisfy the public's demand for visual enjoyment, giving rise to outdoor digital signage.
| The containment structure | The material and feature of shell | IP65 outdoor cabinet, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 55 inch |
| Display area | 1214mm(H) X 684mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 1920X 1080 | |
| Display color | 16.7M | |
| Brightness | 1500 cd/㎡ ~ 2000cd/㎡ | |
| Contrast Ratio | 4000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz |
High Brightness to Capture Attention
As an outdoor display screen, outdoor digital signage needs to have sufficient screen brightness to instantly attract pedestrians' attention. If the screen lacks brightness when outdoor lighting becomes stronger or direct sunlight hits, the advertisement's effectiveness will be greatly compromised.
ZXTLCD Outdoor Digital Signage is equipped with a super-high-brightness display screen, with a brightness of up to 3500 lumens, 1.75 times that of ordinary outdoor digital signage. It also adopts dynamic backlight automatic adjustment design for improved energy efficiency and environmental friendliness.
| Buit-in Media Player | Ads updated type | USB copy by manual operation |
| RAM | 2GB | |
| Flash memory card | 16GB | |
| Plug-and-Play | Plug-and-play /No windows OS, Auto loop play when power on | |
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx | |
| Interface | HDMI | 1 |
| USB | 2 | |
| SD cassette | TF(Micro SD )card, scalable 32G | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month |
Multiple Protections
Outdoor conditions are often variable, with factors such as wind and rain, as well as significant temperature and humidity changes. Therefore, outdoor digital signage needs to be able to operate normally in these environments. Additionally, as an outdoor device, it also needs protection against theft and damage.
ZXTLCD Outdoor Digital Signage features IP65 protection level and MoHS 7-level physical tempered explosion-proof glass. In addition to the traditional waterproof and dustproof features, it excels in theft prevention, explosion protection, lightning protection, and corrosion resistance, providing comprehensive protection.
| Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | below 40℃ ~ + 55℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 280W | |
| The dimension of machine | To be determined | |
| Outer Package size and Gross weight | ||
Sleek and Lightweight Design
Traditional outdoor advertising devices often have a bulky and less aesthetically pleasing appearance due to technological limitations.
ZXTLCD Outdoor Digital Signage undergoes a comprehensive upgrade in appearance, with a more stylish and pleasing design. It has a thinner overall profile, with a thickness as low as 120mm. Combined with high-quality outdoor paint, it offers you a complete visual enjoyment!
Versatile Features
Compared to traditional outdoor advertising, outdoor digital signage offers more diverse forms. It can not only display traditional image ads but also showcase dynamic video advertisements, providing a variety of options for product presentations to meet people's advertising needs.
ZXTLCD Outdoor Digital Signage also includes features such as video splitting, scrolling subtitles, and scheduled on/off, supporting various video and image formats, allowing for flexible playback in both landscape and portrait orientations.
ZXTLCD Outdoor Digital Signage, your reliable advertising companion!
