Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-E190BAWFS |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight cases are optional |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 19 Inch | Aspect Ratio: | 4:3 |
|---|---|---|---|
| Brightness: | 250 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 19-inch Android display is an exceptional tool for enhancing transportation hubs, such as airports, train stations, and bus terminals, where clear and real-time communication is essential. With its high-resolution display and wide viewing angles, this screen ensures that travelers can easily read schedules, gate information, and updates from any position. Its bright and clear display ensures visibility in high-traffic areas, even under direct lighting conditions. The integration of Android OS allows for the flexibility to display dynamic content, including announcements, advertisements, and emergency notifications, all updated in real time. Its robust wireless connectivity ensures seamless communication across multiple displays throughout the hub, ensuring travelers are always informed.
| LCD Panel Parameters | Screen Size | 19 Inch | ||
| Display Area | 376.32 mm.(Height) X 301.06(Width)mm. | |||
| Aspect Ratio | 4 : 3 | |||
| LCD Type | a-Si TFT-LCD Monitor | |||
| Maximum Resolution | 1280 X 1024 | |||
| Display Color | 16.7m , 73% NTSC | |||
| Brightness | 250cd/m² | |||
| Contrast Ratio | 1000 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
| Response Time | 14ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 100Hertz | |||
| Audio parameters | Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
| GPU | Mali-T764 | Mali-G52 | ||
| RAM | 2GB | 4GB | ||
| ROM | 32GB | 32GB | ||
| Android System | Android 10.0 | Android 11.0 | ||
| Ethernet | 1 x RJ45, Ethernet 1,000 Mbps | 1 x RJ45, Ethernet 1,000 Mbps | ||
| Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
| Bluetooth | 4.2 | 5 | ||
| Interface | USB2.0 x 2 | USB2.0 x 2 | ||
| HDMI IN x 1 | ||||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 30 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Package Size | Device Dimensions | 416 X 344 X 55.7 mm. | ||
| Net Weight | 6.5 Kilogram | |||
| Package Size | 50 X 42 X 15 Centimeter | |||
| Gross Package Weight per Unit | 7 Kilogram | |||
In access control systems, the 19-inch Android display offers a secure and efficient way to manage and monitor access points. Whether it's for visitor management or employee identification, this screen serves as a crucial interface in buildings, campuses, or restricted areas. With its touch functionality, users can easily input access codes, scan QR codes, or verify identity using biometrics or smart cards. The Android-based operating system enables easy integration with various security applications, providing a customizable solution for entry management, monitoring security footage, and controlling multiple access points from a central hub. Additionally, its network connectivity ensures that the system remains updated, allowing administrators to manage access rights remotely and make real-time adjustments to security protocols.
The 19-inch Android display also excels in the realm of interactive kiosks in public spaces, such as shopping malls, museums, and exhibition centers. With its multi-touch interface and high-definition display, it provides users with an engaging experience to explore interactive content, such as digital directories, promotional offers, or detailed information about exhibits. Its compact yet powerful design allows it to be installed in a variety of settings, from standalone units to integrated setups in walls or counters. Additionally, the system’s Wi-Fi connectivity and Bluetooth functionality enable seamless data transfer and interaction with nearby devices, making it ideal for both informational and commercial purposes in high-traffic environments.
