Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-E133WAS |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight cases are optional |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 13.3 Inch | Aspect Ratio: | 16:9 |
|---|---|---|---|
| Brightness: | 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 13.3-inch Android monitor offers a dynamic solution for interactive retail kiosks, providing customers with an intuitive and seamless experience. Equipped with a full HD resolution of 1920 x 1080, this display ensures vibrant, crisp visuals for product browsing, self-checkout, or in-store promotions. Retailers can utilize this monitor to showcase digital price tags, advertisements, and interactive menus with impressive clarity, enhancing customer engagement. The Android OS allows for easy integration with various point-of-sale (POS) systems, loyalty programs, and inventory management applications, making it a versatile tool for modern retail environments. With Wi-Fi and Bluetooth connectivity, updates can be remotely managed, enabling real-time changes to content across a network of kiosks.
| LCD Panel Parameters | Screen Size | 13.3 Inch | ||
| Display Area | 293.76 mm.(Height) X 165.24(Width)mm. | |||
| Aspect Ratio | 16 : 9 | |||
| LCD Type | a-Si TFT-LCD Monitor | |||
| Maximum Resolution | 1920 X 1080 | |||
| Display Color | 262K, 45% NTSC | |||
| Brightness | 220cd/m² | |||
| Contrast Ratio | 800 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 85°/85°/85°/85° (Type)(CR≥10) | |||
| Response Time | 30ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Audio parameters | Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
| GPU | Mali-T764 | Mali-G52 | ||
| RAM | 2GB | 4GB | ||
| ROM | 32GB | 32GB | ||
| Android System | Android 10.0 | Android 13.0 | ||
| Ethernet | 1 x RJ45, 1,000 Mbps | Ethernet 1,000 Mbps | ||
| Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
| Bluetooth | 4.2 | 5 | ||
| Interface | USB2.0 x 2 | OTG USB2.0 x 1 | ||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 25 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Package Size | Device Dimensions | 359.9 X 233.9 X 50 mm. | ||
| Net Weight | 3 Kilogram | |||
| Package Size | 42 X 29 X 15Centimeter | |||
| Gross Package Weight per Unit | 4 Kilogram | |||
Ideal for public information systems, the 13.3-inch monitor delivers high-quality content in public spaces such as transportation hubs, airports, and shopping malls. Its wide viewing angles and bright display make it visible from multiple directions, ensuring accessibility and ease of use in crowded or busy environments. It is perfect for wayfinding systems, event schedules, or advertising screens, providing audiences with timely and relevant information. The Android-powered interface allows for easy updates and custom applications, whether for dynamic schedules or emergency notifications. Its compact design and low power consumption make it a reliable, energy-efficient solution for continuous public use.
In corporate environments, this 13.3-inch display serves as an excellent tool for digital signage, enhancing communication and presentation capabilities. Whether used in lobby displays, conference room booking systems, or corporate directories, the monitor ensures clear visibility of critical information. The full HD resolution delivers detailed visuals, making it ideal for showcasing corporate branding, announcements, and real-time updates. Additionally, its Ethernet and Bluetooth connectivity provide the flexibility to connect with other devices in the office, allowing for seamless integration and management of content. With its durable design and extended lifespan, this monitor is a long-term solution for businesses seeking to enhance their digital signage capabilities while maintaining a professional, sleek aesthetic.
