Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-E156WAB |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight cases are optional |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 15.6 Inch | Aspect Ratio: | 16:9 |
|---|---|---|---|
| Brightness: | 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 15.6-inch slim Android display is a powerful and adaptable tool for factory dashboards and automation systems. With its high-definition 1920 x 1080 resolution, this monitor provides clear, precise visuals to display real-time data, machinery status, and operational analytics. Factory floors and manufacturing environments benefit from its bright and vivid display, enabling operators to monitor performance and detect issues with ease. The wide viewing angles ensure that critical information is visible from various positions, which is essential for team collaboration. Furthermore, the Android operating system simplifies integration with custom software solutions, allowing seamless communication between various machinery and automation platforms, improving overall efficiency.
| LCD Panel Parameters | Screen Size | 15.6 Inch | ||
| Display Area | 344.16 mm.(Height) X 193.59(Width)mm. | |||
| Aspect Ratio | 16 : 9 | |||
| LCD Type | a-Si TFT-LCD Monitor | |||
| Maximum Resolution | 1920 X 1080 | |||
| Display Color | 16.7M , 72% NTSC | |||
| Brightness | 250cd/m² | |||
| Contrast Ratio | 700 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
| Response Time | 30ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Audio parameters | Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ω | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
| GPU | Mali-T764 | Mali-G52 | ||
| RAM | 2GB | 4GB | ||
| ROM | 32GB | 32GB | ||
| Android System | Android 10.0 | Android 11.0 | ||
| Ethernet | 1 x RJ45, 1,000 Mbps | Ethernet 1,000 Mbps | ||
| Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
| Bluetooth | 4.2 | 5 | ||
| Interface | USB2.0 x 2 | USB2.0 x 2 | ||
| HDMI IN x 1 | ||||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 30 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Package Size | Device Dimensions | 403.9 X 263.9X 50mm. | ||
| Net Weight | 5 Kilogram | |||
| Package Size | 47 X 33 X 15Centimeter | |||
| Gross Package Weight per Unit | 5.5 Kilogram | |||
In industrial environments, the 15.6-inch Android display can be utilized for real-time monitoring of production lines, inventory tracking, or machine diagnostics. The monitor’s durable design and long lifespan (up to 60,000 hours) make it suitable for continuous, long-term use in demanding conditions. With Wi-Fi and Ethernet connectivity, it easily integrates with IoT-enabled devices and cloud-based automation systems, enabling remote monitoring and control. This makes it ideal for smart factories, where data can be analyzed in real-time to enhance productivity and minimize downtime. Additionally, the multi-touch functionality of the screen ensures that operators can interact with the system directly, providing hands-on control over their operations.
This 15.6-inch display also finds its place in transportation management systems and vehicle fleet tracking. The vibrant, full-HD display allows for clear GPS tracking, traffic monitoring, and vehicle diagnostics, making it an essential part of fleet management dashboards. With its rugged design, it can withstand the vibrations and temperature fluctuations typical of vehicles or transport environments, providing a reliable tool for fleet operators. The inclusion of Bluetooth and USB interfaces ensures that it can be connected with a variety of external devices, including GPS sensors and vehicle monitoring systems. Whether used for live traffic updates, vehicle performance data, or route optimization, the monitor delivers a dynamic and versatile solution for fleet management professionals.
