18.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels

18.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels

  • 18.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels
  • 18.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels
18.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-E185WABWFS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight cases are optional
Delivery Time: 3-5 working days
Payment Terms: L/C,T/T,Western Union,MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 18.5 Inch Aspect Ratio: 16:9
Brightness: 400 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
Highlight:

18.5-Inch Smart Android Monitor

,

Smart Android Monitor for Transportation Systems

,

high contrast ratio Android Display Monitor

18.5-Inch Android Monitor for Transportation Systems and Access Control Panels

The 18.5-inch Android monitor offers a versatile solution for transportation systems, providing real-time data visualization for public transit or vehicle fleet management. Whether it's for bus terminals, train stations, or metro systems, this high-definition screen delivers crucial operational information such as schedules, announcements, or maps with excellent clarity and a 1920 x 1080 resolution. Its high contrast ratio ensures that information remains legible even in well-lit environments, making it ideal for digital signage in busy transportation hubs. The monitor's Android system allows easy integration with custom apps, enabling administrators to remotely update schedules, display alerts, or manage advertising content across multiple locations. Additionally, Wi-Fi 6 connectivity ensures seamless communication between the monitor and central management systems, facilitating efficient coordination across transportation networks.

LCD Panel Parameters Screen Size 18.5 Inch
Display Area 409.8 mm.(Height) X 230.4(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 16.7m , 72% NTSC
Brightness 250cd/m²
Contrast Ratio 1200 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 14ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Audio parameters Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Built-in Android PCB Configuration (Choose one of two) CPU Quad-Core RK3288, 1.8GHz Quad-Core RK3568,2.0GHz
GPU Mali-T764 Mali-G52
RAM 2GB 4GB
ROM 32GB 32GB
Android System Android 10.0 Android 11
Ethernet 1 x RJ45, 1,000 Mbps Ethernet 1,000 Mbps
Wireless Internet 2.4Gigahertz 2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth 4.2 5
Interface USB2.0 x 2 OTG USB2.0 x 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 30 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0℃ ~ 50℃
Storage Temperature Below 10℃ ~ +60℃
Package Size Device Dimensions 470.9 X 294.9 X 56.7 mm
Net Weight 6.5 Kilogram
Package Size 55 X 38 X 17Centimeter
Gross Package Weight per Unit 7 Kilogram


In access control panels, the 18.5-inch Android monitor plays a crucial role in enhancing security and streamlining user interactions. It can be deployed in building entry systems, gated communities, or restricted access areas to display real-time camera feeds, user authentication interfaces, or visitor logs. The large display area and touchscreen functionality offer intuitive navigation for users, enabling smooth access control management. Security personnel can also use the system to display live alerts, communicate with visitors, or verify access credentials. The stereo audio system ensures that announcements or security warnings are delivered clearly, while Bluetooth and USB connectivity provide integration with various peripheral devices like ID card readers or biometric scanners. Whether in office buildings or secure facilities, this monitor can be used to enhance both security and user experience.

18.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels 018.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels 118.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels 218.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels 318.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels 418.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels 518.5-Inch Smart Android Monitor for Transportation Systems and Access Control Panels 6
For interactive kiosks and self-service terminals, the 18.5-inch monitor excels in customer engagement across various industries. In retail stores, airports, or hotel lobbies, it can function as an information hub where customers can check in, access product details, or explore services. The high resolution ensures that images and content are displayed clearly, enhancing the customer experience. Its Android operating system enables it to run dynamic applications, manage content, or serve as a point-of-sale terminal. In ticketing systems, this screen provides an interactive interface for users to select services, purchase tickets, or print boarding passes. The ability to connect to the internet through Ethernet or Wi-Fi ensures real-time updates and easy synchronization with backend systems. This flexible monitor, with its robust performance and adaptable interfaces, is well-suited for a wide range of applications in public service environments, commercial venues, and automated systems.
