Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC/ERP Energy Label |
| Model Number: | ZXTLCD-LD320FSK |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Application: | Outdoor | Supplier Type: | Original Manufacturer, ODM, OEM |
|---|---|---|---|
| Specification: | Digital Poster, Kiosk | Resolution: | 1080P/2K/4K |
| Display Function: | Video Picture Graphic | Usage: | Outdoor Adverting Display |
| After-sales Service Provided: | Online Video Technical Support | Material: | Metal Case + Toughened Glass Panel |
| Function: | SDK | Type: | LCD, Outdoor IP65 |
| Keywords: | Commercial Outdoor Digital Signage Displays / Outdoor Lcd Advertising Displayer |
ZXTLCD's all-weather intelligent outdoor LCD digital signage, equipped with LED backlight technology and an embedded information dissemination system, ensures clear display and playback of images, videos, and scrolling text even under bright lighting conditions. It is not limited by the number of advertisements and offers features such as lightning and power surge protection, dust and waterproofing, energy efficiency, easy installation, convenient maintenance, and low cost. It is widely used in the smart construction of tourist attractions, parks, advertising media, communities, subway stations, bus stops, toll booths, government entities, campuses, commercial streets, upscale residential areas, and other locations.
Smart Communities:
ZXTLCD's 49-inch outdoor vertical digital signage serves as an intelligent parking assistant in communities. With its customized slim design and elegant appearance, it prominently displays the availability of parking spaces in the community parking lot. The LCD screen below can also play text, images, videos, etc., providing information about the community, nearby attractions, promoting social civility, and making the community smarter and more dynamic.
| The containment structure | The material and feature of shell | IP65 outdoor cabinet, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 32 inch |
| Display area | 697mm(H) X 392mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 1080 X 1920 | |
| Display color | 16.7M | |
| Brightness | 1000 cd/㎡ ~ 1500cd/㎡ | |
| Contrast Ratio | 2000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz | |
| Buit-in Media Player | Ads updated type | USB copy by manual operation |
| RAM | 2GB | |
| Flash memory card | 16GB | |
| Plug-and-Play | Plug-and-play /No windows OS, Auto loop play when power on | |
Theme Parks:
ZXTLCD's 32-inch outdoor LCD digital signage, available in hanging, wall-mounted, or vertical configurations, is installed in parks. It not only showcases the theme characteristics of the park but also serves as an excellent alternative to manual assistance. It provides real-time narration of important attractions, park navigation, weather updates, visitor information, local business news, and more. This helps visitors obtain crucial information about the park promptly, even when there is a shortage of park staff, enhancing their sightseeing experience.
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx | |
| Interface | HDMI | 1 |
| USB | 2 | |
| SD cassette | TF(Micro SD )card, scalable 32G | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month | |
| Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | below 40℃ ~ + 55℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 280W | |
| The dimension of machine | To be determined | |
| Outer Package size and Gross weight | ||
Urban Services:
ZXTLCD's large-screen digital signage contributes to the information systems of subways and buses, offering passengers real-time information such as transit maps, service and safety instructions, government announcements, and sports news.
Sports Events:
ZXTLCD's outdoor LCD digital signage can be installed near the spectator stands in sports stadiums, providing player information, live event coverage, on-site analysis, and displaying advertisements to guide and facilitate audience consumption.
