Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC/ERP Energy Label |
| Model Number: | ZXTLCD-LD430BW |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Application: | Application | Color: | Request / Custom |
|---|---|---|---|
| Panel Size: | 43 Inch | Place Of Origin: | Guangdong, China |
| Model Number: | OEM | Brand Name: | ZXTLCD / OEM |
| Use: | Advertising Publish, Retail Store, Shopping Mall, Welcome Display, Self-service Business, Exhibition Hall, Subway, Restaurant & Hotel Supplies | Specification: | Digital Poster |
| Resolution (pixel): | 1920*1080 | Display Contrast: | 16:9 |
| Keywords: | Outdoor Digital Signage / Outdoor LCD Displays |
High-Brightness LCD Screen: Equipped with industrial-grade high-brightness LCD screens that meet the requirements of outdoor HD, high brightness, waterproof, and dustproof. The brightness ranges from 1500 to 2500 cd/m², ensuring clear display even in bright light. The images are vibrant and lifelike.
| The containment structure | The material and feature of shell | IP65 outdoor cabinet, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 43 inch |
| Display area | 530mm(H) X 938mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 1080 X 1920 | |
| Display color | 16.7M | |
| Brightness | 1500 cd/㎡ ~ 2000cd/㎡ | |
| Contrast Ratio | 1000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz |
Wireless Network Transmission: Outdoor Digital Signage eliminates the need for wiring in outdoor plazas. With 4G wireless network capability, content updates and control can be done quickly and easily. It offers simple and secure usage.
Outdoor Heat Dissipation: Outdoor Digital Signage needs to withstand temperature variations throughout the seasons. Current solutions involve installing air conditioning or centrifugal fans to ensure long-term operation at a constant temperature.
| Buit-in Media Player | Ads updated type | USB copy by manual operation |
| RAM | 2GB | |
| Flash memory card | 16GB | |
| Plug-and-Play | Plug-and-play /No windows OS, Auto loop play when power on | |
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx | |
| Interface | HDMI | 1 |
| USB | 2 | |
| SD cassette | TF(Micro SD )card, scalable 32G | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month |
Structural Design: Outdoor Digital Signage meets the IP65 protection level requirement, ensuring a professional heat dissipation channel, convenient maintenance, and a sturdy anti-theft structure. It is designed to withstand outdoor conditions, including lightning, strong winds, corrosion, and explosion prevention.
Multiple Forms of Content Playback: Unlike traditional printed media with one-time advertisements, Outdoor Digital Signage supports various forms of content playback, including videos, music, images, documents, and more.
| Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | below 40℃ ~ + 55℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 280W | |
| The dimension of machine | To be determined | |
| Outer Package size and Gross weight | ||
