Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong province, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC/ERP Energy Label |
| Model Number: | ZXTLCD-LD550FHB |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Panel Brand: | LG / BOE | Color: | Request / Custom, White, Black White |
|---|---|---|---|
| Place Of Origin:: | Shenzhen | Language: | Support Multi-language |
| ANT In (IEC Terrestrial/cable): | 1 Piece | Power Supply: | AC 100V-240V Input |
| Media Available: | Datasheet, Photo, EDA/CAD Models, Other | Specification: | Stretch Bar, Digital Poster, Touch Screen, Video Wall, Kiosk |
| OEM: | Support | Warranty: | 1-3 Years |
| Keywords: | Outdoor Digital Screen |
With the advancement of societal technology, outdoor advertising is rapidly transitioning from traditional static billboards to dynamic digital displays. ZXTLCD Outdoor Digital Signage disseminates information unaffected by weather conditions and offers a visually and audibly appealing experience. It finds extensive applications in outdoor advertising, public information dissemination, media communication, touch interactive queries, and more, enhancing the visual hierarchy and showcasing details. As the usage scenarios of outdoor digital signage expand from semi-outdoor to fully outdoor, it faces increasingly diverse challenges.
| The containment structure | The material and feature of shell | IP65 outdoor cabinet, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 55 inch |
| Display area | 1214mm(H) X 684mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 1920X 1080 | |
| Display color | 16.7M | |
| Brightness | 1500 cd/㎡ ~ 2000cd/㎡ | |
| Contrast Ratio | 4000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz | |
| Buit-in Media Player | Ads updated type | USB copy by manual operation |
| RAM | 2GB | |
| Flash memory card | 16GB | |
| Plug-and-Play | Plug-and-play /No windows OS, Auto loop play when power on | |
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx |
The brightness standard for the outdoor digital signage industry requires achieving a luminance of 1500 cd/m² (referred to as cd hereafter) in unobstructed daylight conditions to be classified as an outdoor display.
| Interface | HDMI | 1 |
| USB | 2 | |
| SD cassette | TF(Micro SD )card, scalable 32G | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month | |
| Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | below 40℃ ~ + 55℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 280W | |
| The dimension of machine | To be determined | |
| Outer Package size and Gross weight | ||
"Anti-glare" technology has been widely applied in everyday life, such as mobile phones, tablets, and monitors. However, for outdoor digital signage, if it doesn't want to become a "public dressing mirror," it requires higher anti-glare specifications. This is particularly crucial when applied in information display scenarios in the transportation industry. Insufficient display clarity or strong light reflections can pose significant risks to road safety. Through unique technology and exclusive patented reflection elimination film, outdoor digital signage enhances image visibility, reduces screen reflections, and improves picture contrast. Moreover, outdoor digital signage not only provides "anti-glare" but also "anti-polarization." By applying circular polarization technology, it addresses the "display blind spots" issue that arises when viewers wearing polarized sunglasses observe traditional LCD displays, ensuring comprehensive road safety.
