Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC/ERP Energy Label |
| Model Number: | ZXTLCD-LD550TDC |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Resolution: | 1920 X 1080 / 3840 X 2160 | Power Supply: | 110V~240V AC |
|---|---|---|---|
| Color: | Optional | Brand Name: | ZXTLCD / OEM |
| WaterProof: | IP65 | Product Name: | Outdoor Lcd Display |
| Working Temperature: | Working Temperature: -40C-50C | Material: | Aluminum Alloy,tempered Glass |
| Surfac: | Spraying,frosted Aluminum | Control Method: | IR Controller, Android Windows OS |
| Keywords: | Commercial Outdoor LCD Signs |
Smart LCD outdoor digital signage integrates 4G, Internet of Things (IoT), and technologies such as mobile payment, QR code, blockchain, and AI, forming an "application experience innovation" driven by informationization and intelligence, which is highly sought after in various industries.
| The containment structure | The material and feature of shell | IP65 outdoor cabinet, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 55 inch |
| Display area | 1214mm(H) X 684mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 1920X 1080 | |
| Display color | 16.7M | |
| Brightness | 1500 cd/㎡ ~ 2000cd/㎡ | |
| Contrast Ratio | 4000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz |
Tourism Industry
In the tourism industry, outdoor digital signage is highly beneficial for promoting and introducing scenic spots, displaying route maps, providing parking information, safety warnings, and commercial advertising. Touchscreen outdoor digital signage can also offer convenient inquiry services, improving service efficiency.
Public Transportation
LCD outdoor digital signage has a wide presence in public transportation areas and can be applied to various systems such as city buses, subways, taxis, and even railway trains. It can display boarding processes, route guidance, voice announcements of schedules, and reminders of relevant events to avoid travel delays.
| Buit-in Media Player | Ads updated type | USB copy by manual operation |
| RAM | 2GB | |
| Flash memory card | 16GB | |
| Plug-and-Play | Plug-and-play /No windows OS, Auto loop play when power on | |
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx | |
| Interface | HDMI | 1 |
| USB | 2 | |
| SD cassette | TF(Micro SD )card, scalable 32G | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month |
Residential Communities
Smart outdoor digital signage in residential communities can provide convenient services for residents, such as inquiries, public announcements, and utility bill inquiries. The application of smart outdoor digital signage not only provides convenience for residents but also greatly enhances the service work of property management companies.
Retail Industry
With the rich display capabilities and vibrant colors of outdoor digital signage, it can effectively enhance the shopping experience of consumers. The advertising dissemination mode of outdoor digital signage is highly effective, with fast content updates and convenient content replacement.
Educational Institutions
When applied in campuses, outdoor digital signage is primarily used for promoting campus culture and displaying high-tech content. It can be used to showcase campus management rules, facilitate school education, and promote student communication.
| Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | below 40℃ ~ + 55℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 280W | |
| The dimension of machine | To be determined | |
| Outer Package size and Gross weight | ||
Hotels
Outdoor digital signage can effectively promote hotel image, service introduction, special offers, latest product information, and announcements, showcasing hotel introductions, signature dishes, pricing, special services, promotions, and notifications in a timely manner.
Residential Areas
When applied in parks, outdoor digital signage can display real-time notifications of park management rules, regulations, and other information, providing better services to the public.
Highways
Outdoor electronic bulletin boards in urban areas play a significant role in promoting culture, advertising, and public notices, making them an important part of smart city development.
Outdoor digital signage can adapt to different advertising forms based on regional characteristics. It can be utilized in commercial streets, squares, parks, transportation vehicles, large shopping malls, real estate, tourist attractions, schools, stations, and other outdoor public spaces with high pedestrian traffic. With rich content and diverse forms of advertising playback, outdoor digital signage achieves better advertising effectiveness compared to traditional advertising mediums that can only convey single-dimensional messages.
If you are interested in the product or have other questions, please feel free to contact us Via WhatsApp.
Contact Person: Alice
Tel: +8615710785838
