Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM150SMT |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 15.6 Inch | Aspect Ratio: | 16：9 |
|---|---|---|---|
| Brightness: | 300 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Highlight: | Embedded Touch Screen for Security Panels,15 Inch Embedded Touch Screen,Embedded Touch Screen for Vending Machines |
||
In the modern manufacturing industry, CNC machine tools are key equipment for achieving precision machining. The 15-inch embedded industrial control machine touchscreen tablet has become an important tool in CNC machine tool operation due to its high-precision touch control and stable performance.
During the operation of CNC machine tools, the 15-inch embedded industrial control machine touchscreen tablet provides operators with a convenient operating experience through its intuitive touch interface. Whether setting processing parameters, adjusting tool paths, or monitoring production status, all can be accomplished through simple touch operations, greatly improving operational efficiency. Its high-resolution display can clearly show complex processing drawings and technical parameters, ensuring operational accuracy. In addition, this tablet has good anti-interference capabilities, allowing it to operate stably in complex electromagnetic environments.
| LCD Panel Parameters | Screen Size | 15 Inch | ||
| Display Area | 304.2 mm.(Height) X 228(Width)mm. | |||
| Aspect Ratio | 16 : 9 | |||
| LCD Type | a-Si TFT-LCD Monitor | |||
| Maximum Resolution | 1024 X 768 | |||
| Display Color | 262K/16.2M , 72% NTSC | |||
| Brightness | 300cd/m² | |||
| Contrast Ratio | 1500 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
| Response Time | 15ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| PCAP Touchscreen Panel Parameters | Touch Pattern | Projected Capacitive Touchscreen Monitor | ||
| Touch Points | 10 Points | |||
| Cover Glass | Morse Glass Size 7 Physically reinforced to prevent explosion | |||
| Glass 3 mm. Optical mount to reduce parallax | ||||
| Glass Transmission | >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85% | |||
| Response Speed | < 6ms | |||
| Touch Accuracy | More than 90% of the touch area ±2 mm | |||
| Touch Method | Inch Stylus | |||
| Output Format | Coordinate Output | |||
| Click Time | Unlimited | |||
| Smallest Touch Size | 5 mm | |||
| Long-lasting Durability | Yes, Available | |||
| Touch Interface | USB | |||
| Operating Temperature and Humidity | Below 10℃ ~ +50℃, ≤ 85%RH | |||
| Storage Temperature and Humidity | Less than 20℃ ~ +60℃, ≤ 90%RH | |||
| Audio Parameters (External Speaker Option) |
Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Onboard Interface | HDMI Input | 1 | ||
| VGA Input | 1 | |||
| DVI Input | 1 | |||
| USB Type B or any desired USB Type | 1 | |||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 25 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Accessories | Power Cord Length | 1.5m | ||
| HDMI Cable Length | 2m | |||
| USB-A to USB-B Cable Length | 1.5m | |||
| Stereo Speaker Size with Connector | 99*45*20mm | |||
| Stereo Speaker Length | 1.5m | |||
| Package Size | Device Dimensions | 351 X 275X 51.7mm. | ||
| Net Weight | 5 Kilogram | |||
| Package Size | 41.2 X 34 X 11Centimeter | |||
| Gross Package Weight per Unit | 5.5 Kilogram | |||
The 15-inch touch industrial tablet not only offers an excellent touch experience but also features a rugged and durable design that is particularly suitable for industrial environments. This tablet features a fully enclosed structure with dustproof and waterproof functions, allowing it to operate stably for long periods under harsh working conditions. Its compact appearance and embedded installation method enable easy integration into the operation panel of CNC machine tools without taking up extra space. Additionally, this tablet supports multiple interfaces, allowing for convenient connections to other devices for real-time data transmission and remote monitoring.
The 15-inch embedded industrial control machine touchscreen tablet, with its outstanding performance and reliable design, is an ideal choice for CNC machine tool operations. Whether improving machining precision or optimizing production processes, this tablet provides powerful support to help enterprises achieve intelligent production.
