Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM270SMT |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 27 Inch | Aspect Ratio: | 16：9 |
|---|---|---|---|
| Brightness: | 300 Cd/m² Max 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Highlight: | Education Systems Embedded Touch Screen,Exhibition Stands Embedded Touch Screen,27 Inch Embedded Touch Screen |
||
In the rapidly developing express cabinet industry, the clarity and stability of the display system are crucial for enhancing user experience. The 27-inch fully enclosed dustproof industrial all-in-one machine, with its high-definition display effect and stable performance, brings a new perspective to the display system in the express cabinet industry.
| LCD Panel Parameters | Screen Size | 27 Inch | ||
| Display Area | 597.6 mm (Height) X 336.15 mm (Width) | |||
| Aspect Ratio | 16 : 9 | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD Monitor | a-Si TFT-LCD Monitor | ||
| Maximum Resolution | 1920 X 1080 | 3840 X 2160 | ||
| Display Color | 16.7m , 99% sRGB | 1.07B , 95% DCI-P3 | ||
| Brightness | 300cd/m² | 400cd/m² | ||
| Contrast Ratio | 1000 : 1 | 1000 :1 | ||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | 89°/89°/89°/89°(Type)(CR≥10) | ||
| Response Time | 14ms | 14ms | ||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| PCAP Touchscreen Panel Parameters | Touch Pattern | Capacitive Touchscreen Capacitive Projected | ||
| Touch Points | 10 Points | |||
| Cover Glass | Morse Glass Size 7 Physically reinforced to prevent explosion | |||
| Glass 3 mm. Optical mount to reduce parallax | ||||
| Glass Transmission | >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85% | |||
| Response Speed | < 6ms | |||
| Touch Accuracy | More than 90% of the touch area ±2 mm | |||
| Touch Method | Inch Stylus | |||
| Output Format | Coordinate Output | |||
| Click Time | Unlimited | |||
| Smallest Touch Size | 5 mm | |||
| Long-lasting Durability | Yes, Available | |||
| Touch Interface | USB | |||
| Operating Temperature and Humidity | Below 10℃ ~ +50℃, ≤ 85%RH | |||
| Storage Temperature and Humidity | Less than 20℃ ~ +60℃, ≤ 90%RH | |||
| Audio Parameters (External Speaker Option) |
Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Onboard Interface | HDMI Input | 1 | ||
| VGA Input | 1 | |||
| DVI Input | 1 | |||
| USB Type B or any desired USB Type | 1 | |||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 45 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Accessories | Power Cord Length | 1.5m | ||
| HDMI Cable Length | 2m | |||
| USB-A to USB-B Cable Length | 1.5m | |||
| Stereo Speaker Size with Connector | 99*45*20 mm | |||
| Stereo Speaker Length | 1.5m | |||
| Package Size | Device Dimensions | 652 X 392 X 51.7 mm. | ||
| Net Weight | 10 Kilogram | |||
| Package Size | 72.3 X 47 X 12Centimeter | |||
| Gross Package Weight per Unit | 11 Kilogram | |||
In the express cabinet industry display system, the 27-inch fully enclosed dustproof industrial all-in-one machine provides users with a clear visual experience with its high-definition display effect. It not only accurately presents express information and operation manuals but also operates various display software stably, providing users with a convenient operating platform. Moreover, its fully enclosed dustproof design allows it to operate stably for long periods in outdoor environments.
At the same time, the 27-inch embedded industrial control machine Windows also plays an important role in the express cabinet industry display system. It can not only operate various systems stably but also be compatible with various display software, providing users with more accurate data. Moreover, its low power consumption design allows it to be used in environments that require long-term operation.
The 27-inch fully enclosed dustproof industrial all-in-one machine and the 27-inch embedded industrial control machine with Windows, with their excellent display effects and stable performance, are becoming new choices for the display systems in the express cabinet industry. They not only enhance user experience but also improve the reliability of the system. In the future, with the continuous advancement of technology, they will play a greater role in the display systems of the express cabinet industry.
