32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms

32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms

  • 32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms
  • 32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms
  • 32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms
  • 32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms
32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-RM320SMT
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight case are option
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 32 Inch Aspect Ratio: 16:9
Brightness: 400 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
Highlight:

Surveillance Systems Embedded Monitor

,

Logistics Operations Embedded Monitor

,

32 Inch Embedded Monitor

32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms

Leading a New Trend in the Film Industry: The 32-inch Windows Embedded Industrial All-in-One Tablet Reshapes the Ticketing Experience



In the wave of digital transformation, the film industry is embracing technology at an unprecedented speed to enhance the audience's viewing experience. As a key component of the cinema's intelligent upgrade, the 32-inch Windows Embedded Industrial All-in-One Tablet, with its outstanding performance and stability, is gradually becoming the preferred solution for ticket machines in the film industry, providing film enthusiasts with a more convenient and efficient ticketing experience.



32-inch Windows Embedded Industrial All-in-One Tablet: The New Standard for Cinema Ticketing

The 32-inch embedded industrial tablet all-in-one machine, equipped with the Windows operating system, perfectly adapts to the complex environment of cinemas with its clear display effect and smooth user interface. Its large screen not only enhances the intuitiveness of information display but also ensures that even during peak hours, audiences can easily complete the ticketing process, reducing wait times and improving overall viewing satisfaction.

32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms 0

32-inch Industrial Windows All-in-One Tablet: Stable and Efficient, Supporting Seamless Cinema Operations

This all-in-one machine, designed specifically for industrial-grade applications, boasts excellent durability and stability, capable of running continuously for long periods without affecting performance, effectively reducing maintenance costs. At the same time, its built-in Windows system has a wealth of software resources, supporting quick access to various ticketing systems, achieving seamless integration of cinema operation management, making cinema management more efficient and convenient.

32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms 1

LCD Panel Parameters Screen Size 32 Inch
Display Area 698.6 mm.(Height) X 394.5(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 8 Bit + FRC Color 1.07G
Brightness 400cd/
Contrast Ratio 1200 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 8ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
PCAP Touchscreen Panel Parameters Touch Pattern Projected Capacitive Touchscreen Monitor
Touch Points 10 Points
Cover Glass Morse Glass Size 7 Physically reinforced to prevent explosion
Glass 3 mm. Optical mount to reduce parallax
Glass Transmission >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85%
Response Speed < 6ms
Touch Accuracy More than 90% of the touch area ±2 mm
Touch Method Inch Stylus
Output Format Coordinate Output
Click Time Unlimited
Smallest Touch Size 5 mm
Long-lasting Durability Yes, Available
Touch Interface USB
Operating Temperature and Humidity Below 10 ~ +50, ≤ 85%RH
Storage Temperature and Humidity Less than 20 ~ +60, ≤ 90%RH
Audio Parameters
(External Speaker Option)
Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Onboard Interface HDMI Input 1
VGA Input 1
DVI Input 1
USB Type B or any desired USB Type 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 60 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Accessories Power Cord Length 1.5m
HDMI Cable Length 2m
USB-A to USB-B Cable Length 1.5m
Stereo Speaker Size with Connector 99*45*20mm
Stereo Speaker Length 1.5m
Package Size Device Dimensions 752 X 446 X 51.7 mm.
Net Weight 13 Kilogram
Package Size 82.3 X 52.5 X 12Centimeter
Gross Package Weight per Unit 15 Kilogram

32-Inch Touch Embedded Monitor for Surveillance Systems, Logistics Operations, Airport Displays, and Control Rooms 2

The 32-inch Windows embedded industrial all-in-one machine, with its excellent display effect, smooth operating experience, and stable industrial-grade quality, is gradually changing the ticketing methods in the film industry, bringing a more intelligent and user-friendly pre-viewing experience to film enthusiasts. In the future, with the continuous advancement of technology, it will demonstrate unlimited potential in more fields, leading a new trend of digital transformation.
