Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM430SMT |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 43 Inch | Aspect Ratio: | 16：9 |
|---|---|---|---|
| Brightness: | 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Highlight: | Large Scale Industrial Monitoring Embedded Screen,43 Inch Embedded Screen,Immersive Digital Advertising Embedded Screen |
||
The global trade volume has been continuously rising, and the efficiency of port cargo systems directly affects the smooth operation of the entire supply chain. To meet the growing transportation demands, port automation has become a trend. Among these, the 43-inch embedded industrial tablet plays an increasingly important role in port cargo automation systems due to its outstanding performance and reliability.
Driven by global trade, port freight automation has become a key link in enhancing logistics efficiency. As a new generation of intelligent control terminal, the 43-inch industrial tablet, with its rugged and durable design and powerful computing capabilities, has become a core component in port freight automation systems. Whether for container tracking management or cargo information processing, this industrial tablet ensures timely and accurate information transmission.
| LCD Panel Parameters | Screen Size | 43 Inch | ||
| Display Area | 941.2 mm.(Height) X 529.4(Width)mm. | |||
| Aspect Ratio | 16 : 9 | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD Monitor | a-Si TFT-LCD Monitor | ||
| Maximum Resolution | 1920 X 1080 | 3840 X 2160 | ||
| Display Color | 16.7m , 72% NTSC | 1.06B, 74% NTSC | ||
| Brightness | 400cd/m² | 400cd/m² | ||
| Contrast Ratio | 1200 : 1 | 1000 :1 | ||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | 89°/89°/89°/89°(Type)(CR≥10) | ||
| Response Time | 8ms | 6ms | ||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| PCAP Touchscreen Panel Parameters | Touch Pattern | Capacitive Touchscreen Capacitive Projected | ||
| Touch Points | 10 Points | |||
| Cover Glass | Morse Glass Size 7 Physically reinforced to prevent explosion | |||
| Glass 3 mm. Optical mount to reduce parallax | ||||
| Glass Transmission | >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85% | |||
| Response Speed | < 6ms | |||
| Touch Accuracy | More than 90% of the touch area ±2 mm | |||
| Touch Method | Inch Stylus | |||
| Output Format | Coordinate Output | |||
| Click Time | Unlimited | |||
| Smallest Touch Size | 5 mm | |||
| Long-lasting Durability | Yes, Available | |||
| Touch Interface | USB | |||
| Operating Temperature and Humidity | Below 10℃ ~ +50℃, ≤ 85%RH | |||
| Storage Temperature and Humidity | Less than 20℃ ~ +60℃, ≤ 90%RH | |||
| Audio Parameters (External Speaker Option) |
Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Onboard Interface | HDMI Input | 1 | ||
| VGA Input | 1 | |||
| DVI Input | 1 | |||
| USB Type B or any desired USB Type | 1 | |||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 90 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Accessories | Power Cord Length | 1.5m | ||
| HDMI Cable Length | 2m | |||
| USB-A to USB-B Cable Length | 1.5m | |||
| Stereo Speaker Size with Connector | 99*45*20mm | |||
| Stereo Speaker Length | 1.5m | |||
| Package Size | Device Dimensions | 1011 X 599 X 66.9 mm. | ||
| Net Weight | 22 Kilogram | |||
| Package Size | 108.6 X 69.6 X 12.5Centimeter | |||
| Gross Package Weight per Unit | 24 Kilogram | |||
The 43-inch capacitive touch industrial control machine computer provides great convenience for port staff with its high-resolution display and intuitive user interface. It can remain clearly visible even under strong outdoor lighting and supports multi-touch functionality, making data entry and command issuance faster and more effective. In addition, this industrial control machine computer also features excellent vibration resistance and dustproof characteristics, allowing it to adapt to the complex environmental conditions of ports and ensuring long-term stable operation.
The 43-inch embedded industrial tablet, with its outstanding performance, has become an indispensable part of the port cargo automation system. It not only helps ports achieve a higher level of automation management but also further promotes technological innovation and development across the entire logistics industry.
