49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels

49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels

  • 49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels
  • 49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels
  • 49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels
  • 49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels
  • 49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels
  • 49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels
49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-RM490SMT
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight case are option
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 49 Inch Aspect Ratio: 16:9
Brightness: 400 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
Highlight:

49 Inch Embedded Touch Display

,

HMI Panels Embedded Touch Display

,

Laboratory Instruments Embedded Touch Display

49-Inch Touch Embedded Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels

49-inch Embedded Capacitive Touch Display: An Efficient Assistant for Multimedia Teaching and Presentations



With the continuous advancement of educational technology, traditional blackboards and projectors have gradually failed to meet the needs of modern classrooms. The emergence of the 49-inch embedded capacitive touch display has brought revolutionary changes to multimedia teaching and presentations. This display, with its large size, high definition, and user-friendly interactive interface, is becoming a powerful tool for enhancing teaching interactivity and efficiency.

49-inch Embedded Capacitive Touch Display: Creating Interactive Learning Spaces

The 49-inch embedded capacitive touch display's large screen and high-definition display capabilities allow every student, regardless of their position in the classroom, to clearly see the content.

Teachers can utilize this display for dynamic presentations, such as analyzing complex scientific experiments or showcasing vivid timelines of historical events, which not only enhances students' visual experience but also helps them better understand and remember the teaching content.

LCD Panel Parameters Screen Size 49 Inch
Display Area 1073.8 mm.(Height) X 604.1 (Width)mm.
Aspect Ratio 16 : 9 16 : 9
LCD Type a-Si TFT-LCD Monitor a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080 3840 X 2160
Display Color 16.7m , 72% NTSC 1.06B, 74% NTSC
Brightness 400cd/ 400cd/
Contrast Ratio 1200 : 1 1000 :1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10) 89°/89°/89°/89°(Type)(CR≥10)
Response Time 8ms 6ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
PCAP Touchscreen Panel Parameters Touch Pattern Capacitive Touchscreen Capacitive Projected
Touch Points 10 Points
Cover Glass Morse Glass Size 7 Physically reinforced to prevent explosion
Glass 3 mm. Optical mount to reduce parallax
Glass Transmission >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85%
Response Speed < 6ms
Touch Accuracy More than 90% of the touch area ±2 mm
Touch Method Inch Stylus
Output Format Coordinate Output
Click Time Unlimited
Smallest Touch Size 5 mm
Long-lasting Durability Yes, Available
Touch Interface USB
Operating Temperature and Humidity Below 10 ~ +50, ≤ 85%RH
Storage Temperature and Humidity Less than 20 ~ +60, ≤ 90%RH
Audio Parameters
(External Speaker Option)
Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Onboard Interface HDMI Input 1
VGA Input 1
DVI Input 1
USB Type B or any desired USB Type 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 90 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Accessories Power Cord Length 1.5m
HDMI Cable Length 2m
USB-A to USB-B Cable Length 1.5m
Stereo Speaker Size with Connector 99*45*20mm
Stereo Speaker Length 1.5m
Package Size Device Dimensions 1144 X 674 X 66.9 mm.
Net Weight 29 Kilogram
Package Size 137.5 X 14.5 X 84.5Centimeter
Gross Package Weight per Unit 32 Kilogram

49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels 0

49-inch Touch Query Display: Promoting Student Engagement and Collaboration

The 49-inch touch query display supports multi-touch functionality, allowing multiple students to operate on the screen simultaneously, greatly facilitating the possibility of collaborative group learning.

Students can collaboratively analyze data, solve problems, or create projects on the display, which not only enhances the fun of learning but also cultivates their teamwork and problem-solving skills.

49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels 1

Embedded capacitive touch query machine: Simplifying the management and use of teaching resources

The built-in smart system of the embedded capacitive touch query machine can easily connect to the school's teaching database, allowing teachers to effortlessly access and display various teaching resources, such as e-books, instructional videos, and interactive software.

In addition, teachers can directly access the internet through the display to introduce the latest teaching materials and information in real-time, ensuring the timeliness and cutting-edge nature of the teaching content.

49-inch embedded capacitive touch display: Enhancing the professionalism and appeal of teaching presentations

The high resolution and wide color gamut display performance of the 49-inch embedded capacitive touch display makes teaching presentations more vivid and professional.

Whether showcasing detailed charts, high-definition images, or playing videos, it presents with excellent visual effects, greatly enhancing the appeal and effectiveness of teaching.

49-Inch Embedded Touch Display for Manufacturing Control Systems, Laboratory Instruments, Public Terminals, and HMI Panels 2

The introduction of the 49-inch embedded capacitive touch display brings a more efficient, interactive, and professional new experience to multimedia teaching and presentations. It not only simplifies the management and use of teaching resources but also enhances the professionalism and appeal of teaching presentations.

With the continuous advancement of technology, future teaching will increasingly rely on such smart devices, which will become key factors in enhancing teaching quality and student learning outcomes.
