Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM101SM |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 10.1 Inch | Aspect Ratio: | 16：9 |
|---|---|---|---|
| Brightness: | 400 Cd/m² Max 1000 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Highlight: | Medical Displays Embedded Monitor,10.1 Inch Embedded Monitor,Factory Dashboards Embedded Monitor |
||
10.1-inch custom industrial control display computer: illuminating a new perspective for subway advertising
In the subway, the artery of the city, an efficient and stable advertising display system has become key to conveying information and attracting passengers' attention. The 10.1-inch custom industrial control display computer, with its professional customization and outstanding performance, is gradually becoming the preferred device for subway advertising screens, adding a touch of vibrant technological color to urban life.
In response to the complex and variable characteristics of the subway environment, this 10.1-inch custom industrial control display computer features a high-brightness, wide-view display screen, ensuring that promotional content is clearly presented in both bright and dim lighting conditions. Its sturdy and durable shell design effectively resists vibrations and dust during subway operations, ensuring the long-term stable operation of the equipment. At the same time, the customized production process allows each display to perfectly integrate into the subway's decorative style, enhancing the overall aesthetic.
As a professional manufacturer of 10.1-inch industrial control computers, we deeply understand the importance of quality for our products. From raw material procurement to production assembly, every step is strictly controlled to ensure that each display leaving the factory meets the highest industry standards. We provide comprehensive after-sales services, including installation and debugging, technical training, and long-term maintenance, allowing customers to use our products without worries. Choosing us means choosing a reliable partner to jointly create a new chapter in subway advertising.
| LCD Panel Parameters | Screen Size | 10.1 Inch | ||
| Display Area | 217 mm.(Height) X 135.6(Width)mm. | |||
| Aspect Ratio | 16 : 9 | 16 : 10 | ||
| LCD Type | a-Si TFT-LCD Monitor | a-Si TFT-LCD Monitor | ||
| Maximum Resolution | 1280 X 800 | 1920 X 1200 | ||
| Display Color | 16.7M, 50% NTSC | 16.2M , 50% NTSC | ||
| Brightness | 400cd/m² | 1000cd/m² | ||
| Contrast Ratio | 900 : 1 | 1000 :1 | ||
| Viewing Angle (Up/Down/Left/Right) | 85°/85°/85°/85° (Type)(CR≥10) | 80°/80°/80°/80° (Type)(CR≥10) | ||
| Response Time | 30ms | 30ms | ||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Audio Parameters (External Speaker Option) |
Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Onboard Interface | HDMI Input | 1 | ||
| VGA Input | 1 | |||
| DVI Input | 1 | |||
| USB Type B or any desired USB Type | 1 | |||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 15 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Accessories | Power Cord Length | 1.5m | ||
| HDMI Cable Length | 2m | |||
| USB-A to USB-B Cable Length | 1.5m | |||
| Stereo Speaker Size with Connector | 99*45*20mm | |||
| Stereo Speaker Length | 1.5m | |||
| Package Size | Device Dimensions | 259.62 X 172.2 X 41.6 mm. | ||
| Net Weight | 2 Kilogram | |||
| Package Size | 31 X 23.3 X 11Centimeter | |||
| Gross Package Weight per Unit | 4 Kilogram | |||
The 10.1-inch custom industrial control display computer demonstrates strong competitiveness in the subway advertising screen field with its professional customization, excellent performance, and reliable quality. It is not only a powerful assistant for subway advertising but also an important window for enhancing the city's image and conveying information. Let us work together to illuminate a new vision for subway advertising!
