13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels

13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels

  • 13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels
  • 13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels
  • 13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels
  • 13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels
  • 13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels
  • 13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels
13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-RM133SM
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight case are option
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 13.3 Inch Aspect Ratio: 16:9
Brightness: 220 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
Highlight:

13.3 Inch Embedded Monitor

,

Warehouse Management Embedded Monitor

,

Industrial Equipment Embedded Monitor

13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels

13.3-inch professional industrial control all-in-one machine: A powerful tool for information display in large transportation venues



In large transportation venues such as airports, train stations, and subway stations, the accurate and timely release of information is crucial for ensuring passengers have a smooth journey. The 13.3-inch professional industrial control all-in-one machine, with its stable and reliable performance and high-definition display effect, has become an important component of the information release system in these venues, providing passengers with clear information display and a comfortable travel experience.



13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels 0

13.3-inch professional industrial control all-in-one machine — A reliable guarantee for information release

In crowded transportation hubs, information display screens need to have high brightness and high contrast to ensure visibility under various lighting conditions. The 13.3-inch professional industrial control all-in-one machine, with its extra-large screen size and high definition resolution, can display important information such as flight dynamics, train schedules, and travel guides, ensuring that passengers can quickly and accurately obtain the information they need. In addition, this all-in-one machine adopts an industrial-grade design, capable of maintaining stability during long periods of continuous operation, meeting the usage demands of large transportation venues.

13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels 1

LCD Panel Parameters Screen Size 13.3 Inch
Display Area 294 mm.(Height) X 165.5(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 262K, 45% NTSC
Brightness 220cd/
Contrast Ratio 800 : 1
Viewing Angle (Up/Down/Left/Right) 85°/85°/85°/85° (Type)(CR≥10)
Response Time 30ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Audio Parameters
(External Speaker Option)
Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Onboard Interface HDMI Input 1
VGA Input 1
DVI Input 1
USB Type B or any desired USB Type 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 25 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Accessories Power Cord Length 1.5m
HDMI Cable Length 2m
USB-A to USB-B Cable Length 1.5m
Stereo Speaker Size with Connector 99*45*20mm
Stereo Speaker Length 1.5m
Package Size Device Dimensions 339 X 219 X 51.7mm.
Net Weight 3 Kilogram
Package Size 38.9 X 27.4 X 11Centimeter
Gross Package Weight per Unit 4 Kilogram

Efficient Management and Maintenance — 13.3-inch Professional Industrial Control Computer

In addition to providing excellent information display capabilities, the 13.3-inch professional industrial control computer also possesses powerful data processing capabilities, supporting various information publishing software and management systems. Whether it's real-time flight information updates or emergency notifications, this device can quickly and accurately convey them to passengers. At the same time, this industrial control machine also supports remote monitoring and maintenance, reducing the need for on-site repairs, lowering operational costs, and ensuring the efficient operation of the information release system.

13.3-Inch Embedded Monitor for Retail Signage, Industrial Equipment Interfaces, Warehouse Management, and Smart Home Panels 2

The 13.3-inch professional industrial control all-in-one display has become an important part of the information release system in large transportation venues due to its outstanding performance and reliability. Whether enhancing passenger experience or optimizing operational management, this device demonstrates its immense value in the transportation industry.
