Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM150SM |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 15 Inch | Aspect Ratio: | 16：9 |
|---|---|---|---|
| Brightness: | 300 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Highlight: | Embedded Monitor for Security Systems,Embedded Monitor for Transportation Displays,15 Inch Embedded Monitor |
||
With the rapid development of smart automotive technology, the demand for high-performance and stable control systems is growing. The 15-inch embedded industrial control all-in-one machine is designed specifically for the smart automotive field, providing a comprehensive control solution that is non-touch but fully functional.
In the field of smart vehicles, the stability and reliability of onboard systems are crucial. The 15-inch embedded industrial control all-in-one machine, with its outstanding performance and durable design, can maintain stable operation even in environments with frequent vibrations and temperature fluctuations, ensuring smooth operation of onboard systems and providing drivers with a reassuring travel experience.
| LCD Panel Parameters | Screen Size | 15 Inch | ||
| Display Area | 304.2 mm.(Height) X 228(Width)mm. | |||
| Aspect Ratio | 16 : 9 | |||
| LCD Type | a-Si TFT-LCD Monitor | |||
| Maximum Resolution | 1024 X 768 | |||
| Display Color | 262K/16.2M , 72% NTSC | |||
| Brightness | 300cd/m² | |||
| Contrast Ratio | 1500 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
| Response Time | 15ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Audio Parameters (External Speaker Option) |
Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Onboard Interface | HDMI Input | 1 | ||
| VGA Input | 1 | |||
| DVI Input | 1 | |||
| USB Type B or any desired USB Type | 1 | |||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 25 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Accessories | Power Cord Length | 1.5m | ||
| HDMI Cable Length | 2m | |||
| USB-A to USB-B Cable Length | 1.5m | |||
| Stereo Speaker Size with Connector | 99*45*20mm | |||
| Stereo Speaker Length | 1.5m | |||
| Package Size | Device Dimensions | 351 X 275X 51.7mm. | ||
| Net Weight | 5 Kilogram | |||
| Package Size | 41.2 X 34 X 11Centimeter | |||
| Gross Package Weight per Unit | 5.5 Kilogram | |||
At the same time, the 15-inch industrial control panel all-in-one machine plays a core role in information interaction within smart vehicles. It is equipped with a high-resolution display that can clearly present navigation, vehicle status, entertainment information, etc., optimizing the flow of information between the driver and the vehicle, thereby enhancing the driving experience.
The 15-inch embedded industrial control all-in-one machine and the 15-inch industrial control panel all-in-one machine, with their stable and reliable performance and clear display effect, are becoming indispensable components in the field of smart automobiles. They not only enhance the driving experience but also promote the advancement of the smart automobile industry. In the future, with the continuous progress of technology, they will play an even greater role in the field of smart automobiles.
