Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM185SM |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 18.5 Inch | Aspect Ratio: | 16：9 |
|---|---|---|---|
| Brightness: | 250 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Highlight: | 18.5 Inch Embedded Monitor,Vending Machines Embedded Monitor,Entertainment Systems Embedded Monitor |
||
With the advancement of technology, smart buildings have become a major trend in the development of modern cities. In this context, an efficient and reliable control system is particularly important. The 18.5-inch industrial control all-in-one machine with Windows, known for its stability and strong compatibility, has become an indispensable core device in the field of smart buildings, providing solid technical support for the automation management of buildings.
In smart buildings, the stability of equipment and the accuracy of data are key to ensuring the normal operation of the system. The 18.5-inch industrial control all-in-one machine with its robust and durable design and stable Windows operating system can operate for long periods without failure, making it suitable for various harsh working environments. Whether monitoring temperature and humidity changes within buildings or managing the operational status of security systems, this industrial control machine can provide accurate data and reliable control.
| LCD Panel Parameters | Screen Size | 18.5 Inch | ||
| Display Area | 411.3 mm.(Height) X 231.4(Width)mm. | |||
| Aspect Ratio | 16 : 9 | |||
| LCD Type | a-Si TFT-LCD Monitor | |||
| Maximum Resolution | 1920 X 1080 | |||
| Display Color | 16.7m , 72% NTSC | |||
| Brightness | 250cd/m² | |||
| Contrast Ratio | 1200 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
| Response Time | 14ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Audio Parameters (External Speaker Option) |
Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Onboard Interface | HDMI Input | 1 | ||
| VGA Input | 1 | |||
| DVI Input | 1 | |||
| USB Type B or any desired USB Type | 1 | |||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 30 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Accessories | Power Cord Length | 1.5m | ||
| HDMI Cable Length | 2m | |||
| USB-A to USB-B Cable Length | 1.5m | |||
| Stereo Speaker Size with Connector | 99*45*20mm | |||
| Stereo Speaker Length | 1.5m | |||
| Package Size | Device Dimensions | 460 X 280 X 51.7mm | ||
| Net Weight | 6.5 Kilogram | |||
| Package Size | 51 X 33.5 X 11Centimeter | |||
| Gross Package Weight per Unit | 7 Kilogram | |||
The 18.5-inch Industrial Control Windows Computer not only boasts excellent performance but also supports various industrial standard protocols, allowing for easy integration into existing building automation systems. Whether it is a building automation system, energy management system, or security monitoring system, this industrial control machine can provide stable data processing capabilities and strong software support, ensuring the coordinated operation of various subsystems. In addition, the openness and ease of use of the Windows platform also facilitate system maintenance and upgrades in the later stages.
The 18.5-inch industrial control all-in-one machine with Windows, known for its outstanding performance and reliable stability, has become an ideal choice in the field of smart buildings. Whether enhancing the management efficiency of buildings or ensuring the comfort and safety of residents, this device demonstrates its significant value in smart buildings.
