17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards

17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards

  • 17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards
  • 17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards
  • 17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards
  • 17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards
  • 17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards
17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-RM170SAT
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight case are option
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 17 Inch Aspect Ratio: 16:9
Brightness: 250 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
Andriod OS: 10.0; 13.0 Config: 2+32GB; 4+32GB
Highlight:

Public Terminals Embedded Touch Display

,

17 Inch Embedded Touch Display

,

Laboratory Instruments Embedded Touch Display

17-Inch Android Touch Embedded Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards

Revolutionizing the Book Borrowing Experience: The 17-inch Android Industrial Control All-in-One Machine Leads a New Trend in Self-Service.



In an era of information explosion, libraries, as the halls of knowledge, are quietly ushering in a revolutionary upgrade in services. Traditional borrowing methods are gradually being replaced by intelligent and self-service service models. Among them, the self-service borrowing machine equipped with a 17-inch Android industrial control all-in-one machine shines brightly in the library borrowing area with its efficiency and convenience, providing readers with an unprecedented borrowing experience.

17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards 0

Reshaping the borrowing process, the 17-inch Android industrial control all-in-one machine showcases its capabilities.

In the busy library borrowing area, rows of 17-inch Android embedded industrial control machines stand quietly; they are not only windows to technology but also key to enhancing service efficiency. This industrial control all-in-one machine, with its large high-definition touchscreen, allows users to easily complete a series of operations such as book inquiries, QR code borrowing, renewals, and returns, significantly reducing waiting times and making the borrowing process simple and efficient.

LCD Panel Parameters Screen Size 17 Inch
Display Area 337.9 mm.(Height) X 270.3(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1280 X 1024
Display Color 16.7M , 72% NTSC
Brightness 250cd/
Contrast Ratio 1200 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 20ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
PCAP Touchscreen Panel Parameters Touch Pattern Projected Capacitive Touchscreen Monitor
Touch Points 10 Points
Cover Glass Physical toughened Morse magnitude 7 explosion-proof
Glass 3 mm. Optical mount to reduce parallax
Glass Transmission >85% (Higher light transmission depends on glass coating technology For example AR/AG) >85%
Response Speed < 6ms
Touch Accuracy More than 90% of the touch area ±2 mm
Touch Method Inch Stylus
Output Format Coordinate Output
Click Time Unlimited
Smallest Touch Size 5 mm
Long-lasting Durability Yes, Available
Touch Interface USB
Operating Temperature and Humidity Below 10 ~ +50, ≤ 85%RH
Storage Temperature and Humidity Less than 20 ~ +60, ≤ 90%RH
Built-in Speaker Power 2 x 5W
Built-in Android PCB Configuration (Choose one of two) CPU Quad-Core RK3288, 1.8GHz Quad-Core RK3568,2.0GHz
GPU Mali-T764 Mali-G52
RAM 2GB 4GB
ROM 32GB 32GB
Android System Android 10.0 Android 13.0
Ethernet 1 x RJ45, 1,000 Mbps Ethernet 1,000 Mbps
Wireless Internet 2.4Gigahertz 2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth 4.2 5
Interface USB2.0 x 2 OTG USB2.0 x 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 30 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Package Size Device Dimensions 385 X 317 X 50.7mm.
Net Weight 5.5 Kilogram
Package Size 44.3 X 38 X 10.5entimeter
Gross Package Weight per Unit 6 Kilogram

17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards 1

17-inch Android embedded industrial control machine, stable and durable, specially designed for industrial environments.

Considering the characteristics of high foot traffic and complex usage environments in libraries, this 17-inch Android industrial control all-in-one machine adopts a high-standard industrial-grade design, featuring dustproof, waterproof, and shock-resistant properties, ensuring stable and reliable performance even during prolonged operation. Its powerful hardware configuration combined with the flexibility of the Android system not only supports the rapid deployment of various application software but also effectively responds to various emergencies, providing solid technical support for library management.

17-Inch Android Embedded Touch Display for Aerospace Control Panels, Public Terminals, Laboratory Instruments, and Factory Dashboards 2

With the continuous development of intelligent technology, the 17-inch Android industrial control all-in-one machine is gradually becoming an indispensable part of the library borrowing area. It not only enhances borrowing efficiency but also enriches the reading experience for users, making the library a bridge connecting knowledge and wisdom. In the future, we have reason to believe that the application of this innovative technology will lead library services into a new stage of greater intelligence and humanization.
