Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM101SA |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 10.1 Inch | Aspect Ratio: | 16：9； 16：10 |
|---|---|---|---|
| Brightness: | 400 Cd/m² Max 1000 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Andriod OS: | 10.0; 13.0 | Config: | 2+32GB; 4+32GB |
| Highlight: | Industrial Dashboards Embedded Screen,Payment Systems Embedded Screen,10.1 Inch Embedded Screen |
||
In the field of smart manufacturing, monitoring and data display on the assembly line are crucial for improving production efficiency. The 10.1-inch Android industrial all-in-one display, designed specifically for smart assembly lines, provides a comprehensive monitoring solution that is non-touch but fully functional.
In smart assembly lines, the clarity and stability of the monitoring dashboard are essential. The 10.1-inch Android industrial all-in-one display offers high-definition display effects, providing users with a clear perspective. It not only accurately presents production data and process status but also ensures real-time updates of monitoring information through stable performance, thereby optimizing the monitoring experience.
At the same time, the 10.1-inch Android industrial control machine also plays an important role in monitoring intelligent assembly lines. It not only operates stably across various systems but also supports various monitoring software, providing users with a convenient data management platform. Moreover, its durable design enables it to operate stably in industrial environments for extended periods, enhancing production efficiency.
| LCD Panel Parameters | Screen Size | 10.1 Inch | ||
| Display Area | 217 mm.(Height) X 135.6(Width)mm. | |||
| Aspect Ratio | 16 : 9 | 16 : 10 | ||
| LCD Type | a-Si TFT-LCD Monitor | a-Si TFT-LCD Monitor | ||
| Maximum Resolution | 1280 X 800 | 1920 X 1200 | ||
| Display Color | 16.7M, 50% NTSC | 16.2M , 50% NTSC | ||
| Brightness | 400cd/m² | 1000cd/m² | ||
| Contrast Ratio | 900 : 1 | 1000 :1 | ||
| Viewing Angle (Up/Down/Left/Right) | 85°/85°/85°/85° (Type)(CR≥10) | 80°/80°/80°/80° (Type)(CR≥10) | ||
| Response Time | 30ms | 30ms | ||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Built-in Speaker | Power | 2 x 5W | ||
| Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
| GPU | Mali-T764 | Mali-G52 | ||
| RAM | 2GB | 4GB | ||
| ROM | 32GB | 32GB | ||
| Android System | Android 10.0 | Android 13.0 | ||
| Ethernet | 1 x RJ45, 1,000 Mbps | Ethernet 1,000 Mbps | ||
| Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
| Bluetooth | 4.2 | 5 | ||
| Interface | USB2.0 x 2 | OTG USB2.0 x 1 | ||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 15 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Package Size | Device Dimensions | 254.2 X 177.62 X 41.6 mm. | ||
| Net Weight | 1.5 Kilogram | |||
| Package Size | 31 X 23.3 X 11Centimeter | |||
| Gross Package Weight per Unit | 3 Kilogram | |||
The 10.1-inch Android industrial all-in-one and the 10.1-inch Android industrial control machine, with their high-definition display effects and stable operating performance, are becoming new choices for monitoring intelligent assembly lines. They not only improve monitoring efficiency but also enhance production efficiency. In the future, with the continuous advancement of technology, they will play a greater role in the field of intelligent manufacturing.
