Place of Origin: | Guangdong, China |
Brand Name: | ZXTLCD |
Certification: | CE/Rohs/FCC |
Model Number: | ZXTLCD-RM133SA |
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiable |
Packaging Details: | wooden case, carton, flight case are option |
Delivery Time: | 3-5 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 2000 pcs per month |
Screen Size: | 13.3 Inch | Aspect Ratio: | 16:9 |
---|---|---|---|
Brightness: | 220 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
Andriod OS: | 10.0; 13.0 | Config: | 2+32GB; 4+32GB |
Highlight: | 13.3 Inch Embedded Monitor,Factory Automation Embedded Monitor,Android Embedded Monitor |
In the wave of digital transformation, unmanned convenience stores, with their convenient and efficient characteristics, are gradually changing people's consumption habits. Behind this, an efficient and stable self-service checkout system has become the key. The 13.3-inch rack-mounted Android industrial control all-in-one machine, with its compact design and powerful performance, injects new vitality into the self-service checkout system for unmanned convenience stores.
Designed specifically for unmanned convenience stores, this 13.3-inch rack-mounted Android industrial control all-in-one machine seamlessly integrates into various checkout layouts, occupying minimal space while delivering powerful functionality. It is equipped with the Android system, ensuring smooth operation and quick response to customer requests, whether for QR code payments, product recognition, or inventory management, effortlessly handling all tasks to ensure a seamless self-checkout process.
As the core of the self-service cashier system, the stability of the 13.3-inch Android industrial control all-in-one machine is crucial. This product has undergone strict quality testing to ensure it remains efficient and stable even after long periods of operation, significantly reducing the failure rate. At the same time, its powerful hardware configuration and optimized software design enable faster and more accurate data processing, providing strong support for the intelligent operation of unmanned convenience stores.
LCD Panel Parameters | Screen Size | 13.3 Inch | ||
Display Area | 294 mm.(Height) X 165.5(Width)mm. | |||
Aspect Ratio | 16 : 9 | |||
LCD Type | a-Si TFT-LCD Monitor | |||
Maximum Resolution | 1920 X 1080 | |||
Display Color | 262K, 45% NTSC | |||
Brightness | 220cd/m² | |||
Contrast Ratio | 800 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 85°/85°/85°/85° (Type)(CR≥10) | |||
Response Time | 30ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 60Hertz | |||
Built-in Speaker | Power | 2 x 5W | ||
Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
GPU | Mali-T764 | Mali-G52 | ||
RAM | 2GB | 4GB | ||
ROM | 32GB | 32GB | ||
Android System | Android 10.0 | Android 13.0 | ||
Ethernet | 1 x RJ45, 1,000 Mbps | Ethernet 1,000 Mbps | ||
Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
Bluetooth | 4.2 | 5 | ||
Interface | USB2.0 x 2 | OTG USB2.0 x 1 | ||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 25 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 339 X 219X 51.7mm. | ||
Net Weight | 3 Kilogram | |||
Package Size | 38.9 X 27.4 X 11Centimeter | |||
Gross Package Weight per Unit | 4 Kilogram |
The 13.3-inch rack-mounted Android industrial control all-in-one machine, with its compact design, powerful performance, and stable and reliable quality, has become the ideal choice for the self-service cashier system in unmanned convenience stores. It not only enhances the shopping experience for customers but also brings more efficient and intelligent operational management methods for businesses. In the new era of smart retail, let us work hand in hand to create brilliance together!
