Place of Origin: | Guangdong, China |
Brand Name: | ZXTLCD |
Certification: | CE/Rohs/FCC |
Model Number: | ZXTLCD-RM156SA |
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiable |
Packaging Details: | wooden case, carton, flight case are option |
Delivery Time: | 3-5 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 2000 pcs per month |
Screen Size: | 15.6 Inch | Aspect Ratio: | 16:9 |
---|---|---|---|
Brightness: | 250 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
Andriod OS: | 10.0; 11.0 | Config: | 2+32GB; 4+32GB |
Highlight: | Retail Displays Embedded Touch Screen,15.6 Inch Embedded Touch Screen,Industrial Dashboards Embedded Touch Screen |
In the steel manufacturing industry, the precise control and efficient operation of CNC equipment are key to ensuring product quality and production efficiency. The 15.6-inch Industrial Control All-in-One Machine Android System, with its stable and reliable performance and flexible operating system, has become an indispensable intelligent control terminal for CNC equipment in the steel manufacturing industry, providing strong technical support for the production process.
In every aspect of steel manufacturing, from raw material processing to finished product inspection, strict control and monitoring are required at every step. The 15.6-inch industrial control all-in-one machine with Android system, with its high-definition display effect and powerful data processing capability, can clearly showcase the operating status and various parameters of the equipment. This all-in-one machine features an embedded installation design, which not only saves space but also adapts to the complex environment of steel manufacturing workshops, ensuring long-term stable operation.
For the steel manufacturing industry, the management and maintenance of CNC equipment are equally important. The 15.6-inch industrial control Android display supports multiple industrial communication protocols, allowing seamless integration with other devices on the production line for real-time data collection and analysis. Based on the openness and ease of use of the Android system, this display can also install customized applications to help operators monitor equipment status more efficiently, promptly identify and resolve issues, thereby improving equipment availability and production efficiency.
LCD Panel Parameters | Screen Size | 15.6 Inch | ||
Display Area | 344.2 mm.(Height) X 193.5(Width)mm. | |||
Aspect Ratio | 16 : 9 | |||
LCD Type | a-Si TFT-LCD Monitor | |||
Maximum Resolution | 1920 X 1080 | |||
Display Color | 16.7M , 72% NTSC | |||
Brightness | 250cd/m² | |||
Contrast Ratio | 700 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
Response Time | 30ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 60Hertz | |||
Built-in Speaker | Power | 2 x 5W | ||
Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
GPU | Mali-T764 | Mali-G52 | ||
RAM | 2GB | 4GB | ||
ROM | 32GB | 32GB | ||
Android System | Android 10.0 | Android 11.0 | ||
Ethernet | 1 x RJ45, 1,000 Mbps | Ethernet 1,000 Mbps | ||
Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
Bluetooth | 4.2 | 5 | ||
Interface | USB2.0 x 2 | USB2.0 x 2 | ||
HDMI IN x 1 | ||||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 30 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 389 X 249X 51.7mm. | ||
Net Weight | 5 Kilogram | |||
Package Size | 44.2 X 30 X 10.5Centimeter | |||
Gross Package Weight per Unit | 5.5 Kilogram |
The 15.6-inch industrial control all-in-one machine with Android system has become an important tool in CNC equipment for the steel manufacturing industry due to its outstanding performance and rich features. Whether improving production efficiency or ensuring product quality, this device demonstrates its significant advantages in the field of industrial automation.
