18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals

18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals

  • 18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals
  • 18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals
  • 18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals
  • 18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals
18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-RM185SA
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight case are option
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 18.5 Inch Aspect Ratio: 16:9
Brightness: 250 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
Andriod OS: 10.0; 11.0 Config: 2+32GB; 4+32GB
Highlight:

18.5-Inch Embedded Monitor

,

Android Embedded Monitor

,

Public Terminals Embedded Monitor

18.5-Inch Android Embedded Monitor for Wayfinding Displays, Fitness Consoles, Entertainment Systems, and Public Terminals

18.5-inch industrial control advertising all-in-one machine embedded screen: A new star in the display of intelligent car washing systems.



With the continuous increase in the number of vehicles, intelligent car washing systems have gradually become a convenient service favored by car owners. To enhance user experience and service efficiency, the 18.5-inch industrial control advertising all-in-one machine embedded screen, with its high definition and stable performance, has become an important display terminal in intelligent car washing systems, providing car owners with clear information and service guidance.

18.5-inch industrial control advertising all-in-one machine embedded screen - the information display window for intelligent car washing

In the intelligent car washing system, clear information display is crucial for enhancing user trust and service transparency. The 18.5-inch industrial control advertising all-in-one machine embedded screen, with its high-resolution display effect, can clearly showcase car washing steps, pricing standards, precautions, and other content. This display screen adopts an embedded design, which not only saves space but also perfectly integrates with the car washing equipment, enhancing the overall aesthetics. Whether it's guiding information before washing or real-time progress during the washing process, everything can be clearly seen on this screen.

18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals 0

System Integration and Efficient Management - 18.5-inch Industrial Control Android Embedded System

In addition to serving as an information display terminal, the 18.5-inch industrial control Android embedded system also possesses powerful data processing and integration capabilities. This system is based on the Android platform, supports various applications and industrial communication protocols, and can easily connect with other components of the car wash system to achieve data sharing and remote management. Whether monitoring the operational status of car wash equipment or updating display content, this embedded system provides stable support to ensure the efficient operation of car wash services.

18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals 1

LCD Panel Parameters Screen Size 18.5 Inch
Display Area 411.3 mm.(Height) X 231.4(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 16.7m , 72% NTSC
Brightness 250cd/
Contrast Ratio 1200 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 14ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Built-in Speaker Power 2 x 5W
Built-in Android PCB Configuration (Choose one of two) CPU Quad-Core RK3288, 1.8GHz Quad-Core RK3568,2.0GHz
GPU Mali-T764 Mali-G52
RAM 2GB 4GB
ROM 32GB 32GB
Android System Android 10.0 Android 11
Ethernet 1 x RJ45, 1,000 Mbps Ethernet 1,000 Mbps
Wireless Internet 2.4Gigahertz 2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth 4.2 5
Interface USB2.0 x 2 OTG USB2.0 x 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 30 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Package Size Device Dimensions 460 X 280 X 51.7mm
Net Weight 6.5 Kilogram
Package Size 51 X 33.5 X 11Centimeter
Gross Package Weight per Unit 7 Kilogram

18.5-Inch Android Embedded Monitor For Wayfinding Displays, Fitness Consoles, Entertainment Systems, And Public Terminals 2

The 18.5-inch industrial control advertising all-in-one embedded screen, with its excellent display effect and stable performance, has become an important component in enhancing user experience and service quality within intelligent car wash systems. This device provides great convenience and assurance for both the managers of car wash shops and the car owners coming for a wash.
