Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM190SA |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 19 Inch | Aspect Ratio: | 4:3 |
|---|---|---|---|
| Brightness: | 250 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Andriod OS: | 10.0; 11.0 | Config: | 2+32GB; 4+32GB |
| Highlight: | 19-Inch Embedded Touch Screen,Android Embedded Touch Screen,Transportation Interfaces Embedded Touch Screen |
||
In the unique setting of mall restrooms, effectively attracting customers' attention and conveying advertising messages is a significant challenge in advertising placement. The 19-inch MES Embedded Industrial Control All-in-One Machine is specifically designed for mall restrooms, offering a comprehensive display solution that is non-touch but fully functional.
In the shopping mall restroom, the 19-inch MES industrial control all-in-one machine, embedded with high-definition display effects, successfully attracted the attention of customers. It not only clearly presents advertising content but also ensures smooth playback of the advertisements through stable performance, thereby enhancing the effectiveness of the ads.
| LCD Panel Parameters | Screen Size | 19 Inch | ||
| Display Area | 375.2 mm.(Height) X 299.2(Width)mm. | |||
| Aspect Ratio | 4 : 3 | |||
| LCD Type | a-Si TFT-LCD Monitor | |||
| Maximum Resolution | 1280 X 1024 | |||
| Display Color | 16.7m , 73% NTSC | |||
| Brightness | 250cd/m² | |||
| Contrast Ratio | 1000 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
| Response Time | 14ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Built-in Speaker | Power | 2 x 5W | ||
| Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
| GPU | Mali-T764 | Mali-G52 | ||
| RAM | 2GB | 4GB | ||
| ROM | 32GB | 32GB | ||
| Android System | Android 10.0 | Android 11.0 | ||
| Ethernet | 1 x RJ45, Ethernet 1,000 Mbps | 1 x RJ45, Ethernet 1,000 Mbps | ||
| Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
| Bluetooth | 4.2 | 5 | ||
| Interface | USB2.0 x 2 | USB2.0 x 2 | ||
| HDMI IN x 1 | ||||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 30 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Package Size | Device Dimensions | 422 X 346 X 51.7mm. | ||
| Net Weight | 6.5 Kilogram | |||
| Package Size | 47.4 X 40.6 X 10.1Centimeter | |||
| Gross Package Weight per Unit | 7 Kilogram | |||
At the same time, the 19-inch closed Android all-in-one industrial control also played an important role in advertising playback in the shopping mall restroom. It not only operates stably across various systems but also is compatible with various advertising software, providing users with a convenient advertising management platform. Moreover, its durable design allows it to operate stably for long periods in the busy shopping mall environment, optimizing advertising effects.
The embedded 19-inch MES industrial control all-in-one machine and the 19-inch closed Android all-in-one machine, with their high-definition display effects and stable operating performance, are becoming a new choice for advertising in shopping mall restrooms. They not only enhance the attractiveness of advertisements but also improve their dissemination effects. In the future, with the continuous advancement of technology, they will play a greater role in the advertising industry.
