Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-RM430SA |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight case are option |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 43 Inch | Aspect Ratio: | 16：9 |
|---|---|---|---|
| Brightness: | 300 Cd/m² Max 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
| Andriod OS: | 10.0; 11.0 | Config: | 2+32GB; 4+32GB |
| Highlight: | 43 Inch Embedded Screen,Stadium Displays Embedded Screen,Gaming Systems Embedded Screen |
||
In the monitoring industry, providing clear and stable monitoring images is a crucial aspect of ensuring safety. The 43-inch automated industrial control Android all-in-one machine is specifically designed for the monitoring industry, providing a comprehensive display solution that is non-touch but fully functional.
In the monitoring industry, the 43-inch automated industrial control Android all-in-one machine provides users with clear monitoring images due to its high definition display. It not only accurately presents monitoring scenes but also ensures real-time updates of monitoring images through stable performance, thereby enhancing monitoring effectiveness.
| LCD Panel Parameters | Screen Size | 43 Inch | ||
| Display Area | 941.2 mm.(Height) X 529.4(Width)mm. | |||
| Aspect Ratio | 16 : 9 | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD Monitor | a-Si TFT-LCD Monitor | ||
| Maximum Resolution | 1920 X 1080 | 3840 X 2160 | ||
| Display Color | 16.7m , 72% NTSC | 1.06B, 74% NTSC | ||
| Brightness | 300cd/m² | 400cd/m² | ||
| Contrast Ratio | 1200 : 1 | 1000 :1 | ||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | 89°/89°/89°/89°(Type)(CR≥10) | ||
| Response Time | 8ms | 6ms | ||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Built-in Speaker | Power | 2 x 5W | ||
| Configuration PCB Android Built-in (Choose one of two) |
CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
| GPU | Mali-T764 | Mali-G52 | ||
| RAM | 2GB | 4GB | ||
| ROM | 32GB | 32GB | ||
| Android System | Android 10.0 | Android 11.0 | ||
| Ethernet | 1 x RJ45, Ethernet 1,000 Mbps | 1 x RJ45, Ethernet 1,000 Mbps | ||
| Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
| Bluetooth | 4.2 | 5 | ||
| Interface | USB2.0 x 2 | USB2.0 x 2 | ||
| HDMI IN x 1 | ||||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 90 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Package Size | Device Dimensions | 1011 X 599 X 66.9 mm. | ||
| Net Weight | 22 Kilogram | |||
| Package Size | 108.6 X 69.6 X 12Centimeter | |||
| Gross Package Weight per Unit | 24 Kilogram | |||
At the same time, the 43-inch Android industrial control system host also plays an important role in the monitoring industry. It not only operates various systems stably but also is compatible with various monitoring software, providing users with a convenient monitoring platform. Moreover, its durable design allows it to operate stably for a long time in complex monitoring environments, optimizing the monitoring experience.
The 43-inch automated industrial control Android all-in-one machine and the 43-inch Android industrial control system host, with their high-definition display effects and stable operating performance, are becoming new choices in the monitoring industry. They not only enhance monitoring effects but also improve monitoring efficiency. In the future, with the continuous advancement of technology, they will play a greater role in the monitoring industry.
