17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels

17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels

  • 17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels
  • 17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels
  • 17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels
  • 17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels
  • 17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels
17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-RM170SW
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight cases are optional
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 17 Inch Aspect Ratio: 16:9
Brightness: 250 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
Windows Versions: 10; 11 CPU: Intel I5-4310M; Intel I5-6100T
RAM+ROM (GB): 4+128; 8+256

17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels



17-inch industrial-grade protective embedded display: A reliable platform for public community information promotion.



In modern society, the importance of information dissemination is self-evident, especially in public communities, where timely and accurate information promotion is crucial for residents' quality of life and community management. The 17-inch industrial-grade protective embedded display, with its robust and durable design and high-definition display effect, has become the ideal choice for public community information promotion, providing residents with clear information presentation and a comfortable viewing experience.

17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels 0

17-inch industrial-grade protective embedded display - a high-definition showcase for information promotion

In public communities, information display screens need to have high clarity and stability to ensure that residents can clearly read announcements, notifications, and other important information. The 17-inch industrial-grade protective embedded display, with its high resolution and wide viewing angle, can present clear and sharp images from any angle. This display features an embedded installation design that not only saves space but also perfectly integrates with the community environment, enhancing overall aesthetics. Whether playing weather forecasts, community activities, or emergency notifications, it can provide excellent visual effects.

17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels 1

LCD Panel Parameters Screen Size 17 Inch
Display Area 337.92 mm.(Height) X 270.3(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1280 X 1024
Display Color 16.7M , 72% NTSC
Brightness 250cd/
Contrast Ratio 1200 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 20ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Audio parameters Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Internal computer configuration
(Choose one of two)
CPU Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics Card Integrated Graphics Card Intel® HD 4600 Integrated Graphics Card Intel® HD 530
RAM 4GB 8GB
Storage Memory Capacity 128GB 256GB
OS Win10 or win11 Optional Win10 or win11 Optional
Wi-Fi Built-in Speed 150Mbps 802.11n wifi Integrated Speed 150Mbps 802.11n wifi Integrated
Media Format Video Format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio Format MP3, WMA
Photo Format BMP, JPEG, PNG, GIF etc.
Onboard Interface Network port RJ45 X 1, 10M/100M Adjustable Ethernet
HDMI 1
USB 4
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 30 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Package Size Device Dimensions 385 X 317 X 51.7mm.
Net Weight 5.5 Kilogram
Package Size 44.3 X 38 X 10.5Centimeter
Gross Package Weight per Unit 6 Kilogram



Community Information Management and Maintenance - 17-inch Industrial Grade Control Display

In addition to providing high-quality display effects, the 17-inch industrial-grade control display also boasts powerful data processing capabilities and reliability. This display supports multiple communication interfaces, allowing for easy connection to the community's information management system, enabling real-time content updates and remote control. Moreover, its robust and durable design can withstand various challenges in outdoor environments, such as temperature fluctuations, humidity, and dust, ensuring long-term stable operation, reducing maintenance costs and failure rates.

17-Inch Windows Embedded Display for Aerospace Applications, Laboratory Instruments, Energy Management Systems, and HMI Panels 2



The 17-inch industrial-grade embedded display, with its outstanding display effects and stable performance, has become an important tool in public community information dissemination. Whether enhancing the effectiveness of information dissemination or optimizing community management, this display has demonstrated its significant value in public communities.
