10.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes

10.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes

  • 10.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes
  • 10.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes
10.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-E101BA
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight cases are optional
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 10.1 Inch Aspect Ratio: 16:9
Brightness: 1000 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
RAM+ROM: 2+32GB; 4+32GB OS: Android 11

10.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes

LCD Panel Parameters Screen Size 10.1 Inch
Display Area 216.58 mm.(Height) X 135.36(Width)mm.
Aspect Ratio 16 : 9 16 : 10
LCD Type a-Si TFT-LCD Monitor a-Si TFT-LCD Monitor
Maximum Resolution 1280 X 800 1920 X 1200
Display Color 16.7M, 50% NTSC 16.2M , 50% NTSC
Brightness 400cd/m² 1000cd/m²
Contrast Ratio 900 : 1 1000 :1
Viewing Angle (Up/Down/Left/Right) 85°/85°/85°/85° (Type)(CR≥10) 80°/80°/80°/80° (Type)(CR≥10)
Response Time 30ms 30ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Audio parameters Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ohm
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Built-in Android PCB Configuration (Choose one of two) CPU Quad-Core RK3288, 1.8GHz Quad-Core RK3568,2.0GHz
GPU Mali-T764 Mali-G52
RAM 2GB 4GB
ROM 32GB 32GB
Android System Android 10.0 Android 13.0
Ethernet 1 x RJ45, 1,000 Mbps Ethernet 1,000 Mbps
Wireless Internet 2.4Gigahertz 2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth 4.2 5
Interface USB2.0 x 2 OTG USB2.0 x 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 15 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0℃ ~ 50℃
Storage Temperature Below 10℃ ~ +60℃
Package Size Device Dimensions 247.4 X 166.4 X 36 mm.
Net Weight 1.5 Kilogram
Package Size 30 X 24 X 10Centimeter
Gross Package Weight per Unit 3 Kilogram



10.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes 010.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes 110.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes 2

10.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes 310.1-Inch Android Embedded Terminal for Retail Kiosks, Medical Devices, Factory Equipment, and Smart Homes 4
