Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-E215BPWFS |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight cases are optional |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 21.5 Inch | Aspect Ratio: | 16:9 |
|---|---|---|---|
| Brightness: | 250 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 21.5-inch Windows display is an excellent solution for industrial dashboards, offering a highly versatile platform for monitoring and controlling various production processes. Whether it’s used for real-time factory data visualization, equipment monitoring, or energy management systems, the screen’s 1920 x 1080 resolution ensures that detailed data is displayed clearly and without distortion. The high contrast ratio of 3000:1 and fast response time of 6.5ms make it ideal for use in automated environments where precision is crucial, enabling operators to respond to changing conditions quickly and efficiently. Moreover, the adjustable brightness and wide viewing angles ensure that the display remains visible and readable even in environments with fluctuating light levels, such as warehouses, manufacturing floors, and control rooms.
| LCD Panel Parameters | Screen Size | 21.5 Inch | ||
| Display Area | 476.5 mm (Height) X 268 mm (Width) | |||
| Aspect Ratio | 16 : 9 | |||
| LCD Type | TFT-LCD Monitor | |||
| Maximum Resolution | 1920 X 1080 | |||
| Display Color | 16.7m | |||
| Brightness | 250cd/m² | |||
| Contrast Ratio | 3000 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 89/89/89/89 (Type)(CR≥10) | |||
| Response Time | 6.5ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Audio parameters | Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Internal computer configuration (Choose one of two) |
CPU | Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz | Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz | |
| Graphics Card | Integrated Graphics Card Intel® HD 4600 | Integrated Graphics Card Intel® HD 530 | ||
| RAM | 4GB | 8GB | ||
| Storage Memory Capacity | 128GB | 256GB | ||
| OS | Win10 or win11 Optional | Win10 or win11 Optional | ||
| Wi-Fi Built-in | Speed 150Mbps 802.11n wifi Integrated | Speed 150Mbps 802.11n wifi Integrated | ||
| Media Format | Video Format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. | ||
| Audio Format | MP3, WMA | |||
| Photo Format | BMP, JPEG, PNG, GIF etc. | |||
| Onboard Interface | Network port | RJ45 X 1, 10M/100M Adjustable Ethernet | ||
| HDMI | 1 | |||
| USB | 4 | |||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 45 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Package Size | Device Dimensions | 515.4 X 312 X 55.7 mm. | ||
| Net Weight | 7 Kilogram | |||
| Package Size | 60 X 40 X 15Centimeter | |||
| Gross Package Weight per Unit | 7.5 Kilogram | |||
In public information systems, the 21.5-inch monitor can be seamlessly integrated into kiosks and digital signage platforms. From wayfinding directories in large shopping malls to transportation information displays in airports and bus terminals, this screen offers optimal visibility and clarity. Its full HD resolution and high brightness make it particularly suitable for environments with high ambient light, ensuring that messages are seen clearly by a wide audience. Furthermore, its wide-angle viewing and stereo audio capabilities provide an immersive experience for users engaging with interactive content, such as tourist information systems, digital directories, or public service announcements.
The 21.5-inch screen is also well-suited for interactive control panels in various sectors, including retail, healthcare, and hospitality. With its touchscreen compatibility (optional) and high-performance specs, it can be used for customer self-service stations, interactive check-in kiosks, and automated ordering systems. In the healthcare industry, it can be integrated into patient monitoring stations or medical device controls, offering real-time data visualization that’s critical for patient care. Whether used in conference rooms, restaurants, or medical facilities, this display provides a reliable, high-quality interface that enhances user engagement and operational efficiency, making it a valuable asset in a wide range of commercial and industrial applications.
