15-Inch Android Screen for Factory Automation and Industrial HMI Solutions

15-Inch Android Screen for Factory Automation and Industrial HMI Solutions

  • 15-Inch Android Screen for Factory Automation and Industrial HMI Solutions
  • 15-Inch Android Screen for Factory Automation and Industrial HMI Solutions
15-Inch Android Screen for Factory Automation and Industrial HMI Solutions
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-E150BA
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight cases are optional
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 15 Inch Aspect Ratio: 16:9
Brightness: 250 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An
RAM+ROM: 2+32GB; 4+32GB OS: Android 11

15-Inch Android Screen for Factory Automation and Industrial HMI Solutions

The 15-inch Android display is an ideal solution for factory automation and industrial human-machine interfaces (HMI), offering robust features to streamline operations and improve efficiency. With its high-definition 1920x1080 resolution and wide viewing angles, the monitor ensures clear and precise control over machinery, processes, and workflows. Whether used in production line monitoring, process control stations, or machine operation panels, this display offers real-time data visualization and integration with automated systems. Its quad-core processor, Android OS, and Ethernet connectivity allow for seamless communication between devices, ensuring that operators can stay connected with critical equipment, update settings remotely, and troubleshoot issues in real time, all from a centralized interface.

LCD Panel Parameters Screen Size 15.6 Inch
Display Area 344.16 mm.(Height) X 193.59(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 16.7M , 72% NTSC
Brightness 250cd/
Contrast Ratio 700 : 1
Viewing Angle (Up/Down/Left/Right) 89°/89°/89°/89° (Type)(CR≥10)
Response Time 30ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Audio parameters Audio system Stereo
Speaker size ≈ 99 x 45 x 20 mm
Impedance 8 Ω
Power 2 x 5 Watt
Loudness > 80 Decibel
Interface 4-pin connector
Built-in Android PCB Configuration (Choose one of two) CPU Quad-Core RK3288, 1.8GHz Quad-Core RK3568,2.0GHz
GPU Mali-T764 Mali-G52
RAM 2GB 4GB
ROM 32GB 32GB
Android System Android 10.0 Android 11.0
Ethernet 1 x RJ45, 1,000 Mbps Ethernet 1,000 Mbps
Wireless Internet 2.4Gigahertz 2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth 4.2 5
Interface USB2.0 x 2 USB2.0 x 2
HDMI IN x 1
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 30 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0 ~ 50
Storage Temperature Below 10 ~ +60
Package Size Device Dimensions 383.4 X 243.4X 49mm.
Net Weight 5 Kilogram
Package Size 45 X 32 X 15Centimeter
Gross Package Weight per Unit 5.5 Kilogram



In industries like manufacturing, this 15-inch monitor plays a pivotal role in ensuring machine health monitoring and predictive maintenance. With its ability to connect to various devices through USB and HDMI interfaces, it can serve as a central hub for diagnostics and system checks. By incorporating real-time alerts, the display enhances operational safety by showing warning signals or performance issues directly on the screen, helping staff take immediate action before problems escalate. The Android operating system allows for flexibility in integrating custom software tailored to specific factory processes, making it an excellent choice for automated control in smart factories and industrial automation solutions. Its low power consumption also ensures it runs efficiently in environments with a high number of devices, saving energy without compromising performance.

15-Inch Android Screen for Factory Automation and Industrial HMI Solutions 0

15-Inch Android Screen for Factory Automation and Industrial HMI Solutions 115-Inch Android Screen for Factory Automation and Industrial HMI Solutions 2

15-Inch Android Screen for Factory Automation and Industrial HMI Solutions 315-Inch Android Screen for Factory Automation and Industrial HMI Solutions 4

Beyond industrial environments, the 15-inch Android monitor is perfect for logistics management systems where real-time tracking of inventory, deliveries, and assets is crucial. Integrated into warehouse management systems, it can display vital information about stock levels, shipping statuses, and routing data, ensuring quick decision-making. In environments like logistics hubs or distribution centers, operators can use the device to interact with data in real time, adjusting workflows or rerouting tasks as needed. With Wi-Fi connectivity, it enables seamless communication with cloud-based applications, enhancing the agility of logistics teams. Whether deployed as a fleet management display or in inventory tracking stations, its robust Android platform and multi-network support make it a versatile tool that integrates easily into a variety of operational environments.
