Place of Origin: | Guangdong, China |
Brand Name: | ZXTLCD |
Certification: | CE/Rohs/FCC |
Model Number: | ZXTLCD-E236BAWFS |
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiable |
Packaging Details: | wooden case, carton, flight cases are optional |
Delivery Time: | 3-5 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 2000 pcs per month |
Screen Size: | 23.6 Inch | Aspect Ratio: | 16:9 |
---|---|---|---|
Brightness: | 250 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 23.6-inch Android display is an excellent solution for logistics monitoring in warehouses, distribution centers, and supply chain management. Its large, high-resolution display allows for clear visualization of key operational data, such as inventory levels, shipping statuses, and real-time tracking of goods. The Android operating system enhances the flexibility of the device by supporting custom apps tailored to specific logistics needs. Coupled with Wi-Fi and Ethernet connectivity, the device can seamlessly integrate into existing automation systems, providing easy access to cloud-based platforms and enhancing the efficiency of warehouse management systems (WMS). The screen’s wide viewing angles ensure that data is accessible from multiple locations within the warehouse, improving collaboration and decision-making.
LCD Panel Parameters | Screen Size | 23.6 Inch | ||
Display Area | 522 mm.(Height) X 294(Width)mm. | |||
Aspect Ratio | 16 : 9 | |||
LCD Type | a-Si TFT-LCD Monitor | |||
Maximum Resolution | 1920 X 1080 | |||
Display Color | 16.7m , 72% NTSC | |||
Brightness | 250cd/m² | |||
Contrast Ratio | 1000 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
Response Time | 14ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 100Hertz | |||
Audio parameters | Audio system | Stereo | ||
Speaker size | ≈ 99 x 45 x 20 mm | |||
Impedance | 8 Ohm | |||
Power | 2 x 5 Watt | |||
Loudness | > 80 Decibel | |||
Interface | 4-pin connector | |||
Configuration PCB Android Built-in (Choose one of two) |
CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
GPU | Mali-T764 | Mali-G52 | ||
RAM | 2GB | 4GB | ||
ROM | 32GB | 32GB | ||
Android System | Android 10.0 | Android 11.0 | ||
Ethernet | 1 x RJ45, Ethernet 1,000 Mbps | 1 x RJ45, Ethernet 1,000 Mbps | ||
Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
Bluetooth | 4.2 | 5 | ||
Interface | USB2.0 x 2 | USB2.0 x 2 | ||
HDMI IN x 1 | ||||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 45 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 564.4 X 340.4 X 55.7mm. | ||
Net Weight | 8 Kilogram | |||
Package Size | 54 X 42 X 15Centimeter | |||
Gross Package Weight per Unit | 9 Kilogram |
In manufacturing environments, the 23.6-inch display acts as a control center for automation systems, offering a central hub for monitoring production lines, machinery, and other critical equipment. The screen’s high resolution ensures that operators can see detailed performance metrics, real-time alerts, and diagnostics, enabling rapid troubleshooting. With its robust Android platform, it can integrate with Industrial Internet of Things (IIoT) devices and sensors, creating a comprehensive automation system. Additionally, the device supports Bluetooth and Wi-Fi connectivity, facilitating easy communication between devices, systems, and cloud services. This makes it ideal for industrial settings, where precision and timely data access are crucial for minimizing downtime and optimizing production processes.
The 23.6-inch Android display is also perfectly suited for interactive digital signage in logistics hubs, transportation terminals, and smart retail spaces. In these environments, the display can be used to showcase important information such as arrival and departure schedules, cargo tracking, or customer-facing advertisements. Its multi-connectivity features, including USB ports and HDMI input, make it easy to integrate with external media players, cameras, and other devices. Whether used for wayfinding systems, digital billboards, or automated customer service kiosks, this device offers a highly flexible and user-friendly solution. With its large screen, clear audio, and Android-based customization options, it can cater to a wide range of applications, enhancing operational efficiency and customer experience in logistics and public transport systems.
