Place of Origin: | Guangdong, China |
Brand Name: | ZXTLCD |
Certification: | CE/Rohs/FCC |
Model Number: | ZXTLCD-E190WAB |
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiable |
Packaging Details: | wooden case, carton, flight cases are optional |
Delivery Time: | 3-5 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 2000 pcs per month |
Screen Size: | 19.0 Inch | Aspect Ratio: | 16:9 |
---|---|---|---|
Brightness: | 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 19-inch Android display is a key solution for transportation interfaces, offering enhanced performance for various transport management systems. Whether used in bus terminals, train stations, or subway systems, this compact monitor ensures clear visibility for passengers and staff. The 1280 x 1024 resolution and 16.7M colors provide crisp, detailed displays, which is essential for showing real-time train schedules, bus arrival times, and route maps. The screen’s wide viewing angles and 250cd/m² brightness ensure that information remains easily readable, even in brightly lit or high-traffic areas. Additionally, the Android-powered interface supports real-time updates, offering seamless integration with transportation management systems, making it perfect for large-scale urban transport applications.
LCD Panel Parameters | Screen Size | 19 Inch | ||
Display Area | 376.32 mm.(Height) X 301.06(Width)mm. | |||
Aspect Ratio | 4 : 3 | |||
LCD Type | a-Si TFT-LCD Monitor | |||
Maximum Resolution | 1280 X 1024 | |||
Display Color | 16.7m , 73% NTSC | |||
Brightness | 250cd/m² | |||
Contrast Ratio | 1000 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
Response Time | 14ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 60Hertz | |||
Audio parameters | Audio system | Stereo | ||
Speaker size | ≈ 99 x 45 x 20 mm | |||
Impedance | 8 Ohm | |||
Power | 2 x 5 Watt | |||
Loudness | > 80 Decibel | |||
Interface | 4-pin connector | |||
Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
GPU | Mali-T764 | Mali-G52 | ||
RAM | 2GB | 4GB | ||
ROM | 32GB | 32GB | ||
Android System | Android 10.0 | Android 11.0 | ||
Ethernet | 1 x RJ45, Ethernet 1,000 Mbps | 1 x RJ45, Ethernet 1,000 Mbps | ||
Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
Bluetooth | 4.2 | 5 | ||
Interface | USB2.0 x 2 | USB2.0 x 2 | ||
HDMI IN x 1 | ||||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 30 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 436.5 X 364.5 X 50 mm. | ||
Net Weight | 6.5 Kilogram | |||
Package Size | 52 X 44 X 15 Centimeter | |||
Gross Package Weight per Unit | 7 Kilogram |
This Android-based monitor is also an invaluable tool for access control systems in various environments. From secure office buildings to high-security facilities, the device provides an ideal interface for monitoring and managing access points. It can display detailed security alerts, visitor management systems, and access logs with high clarity and precision. The 2GB RAM and 32GB storage capacity, along with the Ethernet and Wi-Fi connectivity, ensure smooth operation of access control software while supporting fast data retrieval for security personnel. The stereo audio system also allows for audible alerts or voice instructions, enhancing the system’s responsiveness. This makes it a perfect choice for environments requiring high security and efficient management of restricted areas.
Beyond its uses in transportation and security, the 19-inch Android monitor is also well-suited for interactive kiosks in commercial and public settings. Whether deployed in shopping malls, airports, or information centers, this screen can deliver engaging digital signage and interactive displays. The high definition display combined with the Android operating system allows for a wide range of applications, from wayfinding systems to product information displays. Businesses can take advantage of the device’s ability to run custom apps, allowing for real-time updates and customer interactions. The low power consumption ensures that businesses can operate it 24/7 with minimal energy costs, while the responsive interface enables a seamless, user-friendly experience for customers and visitors alike.
