15.6-Inch Compact Android Display for Factory Dashboards and Security Solutions

15.6-Inch Compact Android Display for Factory Dashboards and Security Solutions

  • 15.6-Inch Compact Android Display for Factory Dashboards and Security Solutions
  • 15.6-Inch Compact Android Display for Factory Dashboards and Security Solutions
15.6-Inch Compact Android Display for Factory Dashboards and Security Solutions
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-E156WASWFS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight cases are optional
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 15.6 Inch Aspect Ratio: 16:9
Brightness: 400 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An

15.6-Inch Compact Android Display for Factory Dashboards and Security Solutions

The 15.6-inch Android display is a robust and efficient solution for industrial dashboards, offering real-time monitoring and control capabilities for factories and production facilities. With a Full HD resolution and high brightness, it enables operators to effectively view essential production data, such as machine status, system alerts, and performance metrics. The device is designed to integrate seamlessly with IoT-based factory management systems using its Ethernet and Wi-Fi 6 connectivity, allowing for remote monitoring and control from anywhere. Additionally, the Android operating system provides the flexibility to run custom applications tailored to the factory's specific needs, making this display perfect for managing production lines, controlling machinery, and even monitoring energy consumption in large-scale industrial operations.

LCD Panel ParametersScreen Size15.6 Inch
Display Area344.16 mm.(Height) X 193.59(Width)mm.
Aspect Ratio16 : 9
LCD Typea-Si TFT-LCD Monitor
Maximum Resolution1920 X 1080
Display Color16.7M , 72% NTSC
Brightness250cd/m²
Contrast Ratio700 : 1
Viewing Angle (Up/Down/Left/Right)89°/89°/89°/89° (Type)(CR≥10)
Response Time30ms
LCD Panel Lifespan (Hours)60,000(Hour.)
Field Frequency60Hertz
Audio parametersAudio systemStereo
Speaker size≈ 99 x 45 x 20 mm
Impedance8 Ω
Power2 x 5 Watt
Loudness> 80 Decibel
Interface4-pin connector
Built-in Android PCB Configuration (Choose one of two)CPUQuad-Core RK3288, 1.8GHzQuad-Core RK3568,2.0GHz
GPUMali-T764Mali-G52
RAM2GB4GB
ROM32GB32GB
Android SystemAndroid 10.0Android 11.0
Ethernet1 x RJ45, 1,000 MbpsEthernet 1,000 Mbps
Wireless Internet2.4Gigahertz2.4Gigahertz/5Gigahertz, Wi-Fi 6
Bluetooth4.25
InterfaceUSB2.0 x 2USB2.0 x 2
HDMI IN x 1
PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
Maximum Power Loss≤ 30 Watt
Standby Mode Power Loss< 1 Watt
FeaturesOperating Temperature0℃ ~ 50℃
Storage TemperatureBelow 10℃ ~ +60℃
Package SizeDevice Dimensions403.9 X 263.9X 56.7 mm.
Net Weight5 Kilogram
Package Size47 X 33 X 17 Centimeter
Gross Package Weight per Unit5.5 Kilogram


For security solutions, the 15.6-inch Android display offers a reliable and efficient interface for managing surveillance systems, from monitoring CCTV feeds to controlling access points in secured areas. The screen’s high contrast ratio and wide viewing angles ensure that every detail is clear and visible, even in low-light conditions or across multiple monitoring stations. Security personnel can easily interact with the system through its touch interface, making adjustments to camera angles, accessing archived footage, or setting up alerts. The USB, HDMI, and Ethernet ports enable easy integration with other security equipment, such as DVRs or NVRs, providing a unified, all-in-one solution for large-scale surveillance systems in places like corporate offices, public buildings, or warehouses.
15.6-Inch Compact Android Display for Factory Dashboards and Security Solutions 015.6-Inch Compact Android Display for Factory Dashboards and Security Solutions 115.6-Inch Compact Android Display for Factory Dashboards and Security Solutions 215.6-Inch Compact Android Display for Factory Dashboards and Security Solutions 315.6-Inch Compact Android Display for Factory Dashboards and Security Solutions 415.6-Inch Compact Android Display for Factory Dashboards and Security Solutions 515.6-Inch Compact Android Display for Factory Dashboards and Security Solutions 6
In interactive kiosks or point-of-sale (POS) systems, the 15.6-inch display shines as a customer-facing interface in retail environments. The screen’s compact design and responsive touch technology make it perfect for providing customers with an engaging and intuitive user experience, whether they are ordering food, checking out at a store, or using a self-service terminal. The display’s Android OS allows for easy customization of the interface to suit the brand's style and functionality, and its low power consumption ensures cost-effective, long-term use. With high-definition graphics and clear sound output from the built-in stereo speakers, it’s an ideal choice for dynamic and interactive customer experiences in shopping malls, restaurants, or ticketing systems at entertainment venues like cinemas and theme parks.
