Give your amazing touch and visual experience !!!
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | ZXTLCD |
| Certification: | CE/Rohs/FCC |
| Model Number: | ZXTLCD-E190WAS |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden case, carton, flight cases are optional |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 pcs per month |
| Screen Size: | 19.0 Inch | Aspect Ratio: | 16:9 |
|---|---|---|---|
| Brightness: | 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 19-inch Android display offers robust performance for transportation systems, serving as a reliable interface for everything from bus stations to airport terminals. With its high-definition resolution and wide viewing angles, this monitor is perfect for displaying real-time updates such as schedules, maps, and traffic alerts. The 250cd/m² brightness ensures the screen is legible even in well-lit environments, crucial for busy stations or transportation hubs. Additionally, the Android-powered system provides seamless connectivity to existing systems, supporting both Ethernet and Wi-Fi for dynamic updates and continuous information flow, making it an excellent tool for transportation management software and digital signage.
| LCD Panel Parameters | Screen Size | 19 Inch | ||
| Display Area | 376.32 mm.(Height) X 301.06(Width)mm. | |||
| Aspect Ratio | 4 : 3 | |||
| LCD Type | a-Si TFT-LCD Monitor | |||
| Maximum Resolution | 1280 X 1024 | |||
| Display Color | 16.7m , 73% NTSC | |||
| Brightness | 250cd/m² | |||
| Contrast Ratio | 1000 : 1 | |||
| Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
| Response Time | 14ms | |||
| LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
| Field Frequency | 60Hertz | |||
| Audio parameters | Audio system | Stereo | ||
| Speaker size | ≈ 99 x 45 x 20 mm | |||
| Impedance | 8 Ohm | |||
| Power | 2 x 5 Watt | |||
| Loudness | > 80 Decibel | |||
| Interface | 4-pin connector | |||
| Built-in Android PCB Configuration (Choose one of two) | CPU | Quad-Core RK3288, 1.8GHz | Quad-Core RK3568,2.0GHz | |
| GPU | Mali-T764 | Mali-G52 | ||
| RAM | 2GB | 4GB | ||
| ROM | 32GB | 32GB | ||
| Android System | Android 10.0 | Android 11.0 | ||
| Ethernet | 1 x RJ45, Ethernet 1,000 Mbps | 1 x RJ45, Ethernet 1,000 Mbps | ||
| Wireless Internet | 2.4Gigahertz | 2.4Gigahertz/5Gigahertz, Wi-Fi 6 | ||
| Bluetooth | 4.2 | 5 | ||
| Interface | USB2.0 x 2 | USB2.0 x 2 | ||
| HDMI IN x 1 | ||||
| Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
| Maximum Power Loss | ≤ 30 Watt | |||
| Standby Mode Power Loss | < 1 Watt | |||
| Features | Operating Temperature | 0℃ ~ 50℃ | ||
| Storage Temperature | Below 10℃ ~ +60℃ | |||
| Package Size | Device Dimensions | 436.5 X 364.5 X 50 mm. | ||
| Net Weight | 6.5 Kilogram | |||
| Package Size | 52 X 44 X 15 Centimeter | |||
| Gross Package Weight per Unit | 7 Kilogram | |||
Designed for access control applications, this versatile display excels in environments requiring secure and efficient monitoring. Whether used in corporate offices, government buildings, or high-security zones, it provides an ideal interface for managing entry points and viewing surveillance footage. The device’s high contrast ratio and clear resolution ensure detailed visibility of security alerts, employee access logs, and visitor tracking. With built-in Bluetooth, Ethernet, and Wi-Fi capabilities, it integrates effortlessly with various access control systems. Moreover, its stereo audio system delivers audible alerts, providing additional layers of security and responsiveness to unauthorized access attempts or emergency events.
Beyond security systems and transportation hubs, this 19-inch Android display is a powerful tool for interactive kiosks and customer service stations. Perfect for shopping malls, information desks, or exhibition centers, it can deliver engaging content such as product catalogs, interactive directories, or digital ads. The device's responsive touch interface and Android OS allow for a customized experience, enabling businesses to showcase real-time promotions or customer feedback forms. With low power consumption and flexible installation options, this display provides a cost-effective solution for continuous operation in high-traffic public spaces. Whether for wayfinding, self-check-in stations, or retail displays, its sleek, compact design ensures seamless integration into a variety of environments.
