15.6-Inch Slim Windows Display for Factory Dashboards and Security Systems

15.6-Inch Slim Windows Display for Factory Dashboards and Security Systems

  • 15.6-Inch Slim Windows Display for Factory Dashboards and Security Systems
  • 15.6-Inch Slim Windows Display for Factory Dashboards and Security Systems
15.6-Inch Slim Windows Display for Factory Dashboards and Security Systems
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-E156WPSWFS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight cases are optional
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 15.6 Inch Aspect Ratio: 16:9
Brightness: 400 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An

15.6-Inch Slim Windows Display for Factory Dashboards and Security Systems

The 15.6-inch Windows display offers robust functionality for factory dashboards and industrial control applications. With a high-definition resolution of 1920x1080, it provides operators with detailed insights into manufacturing processes, real-time data on production metrics, and critical system alerts. The compact design makes it an ideal choice for space-constrained factory floors, where visual data is crucial but room is limited. Its versatile mounting options enable it to be easily positioned on workstations, walls, or control panels, creating an optimized monitoring setup. Moreover, the built-in Wi-Fi connectivity allows seamless communication with the main control system, ensuring that operators are always updated with the latest information across the factory floor, supporting real-time decision-making.

LCD Panel ParametersScreen Size15.6 Inch
Display Area344.16 mm.(Height) X 193.59(Width)mm.
Aspect Ratio16 : 9
LCD Typea-Si TFT-LCD Monitor
Maximum Resolution1920 X 1080
Display Color16.7M , 72% NTSC
Brightness250cd/m²
Contrast Ratio700 : 1
Viewing Angle (Up/Down/Left/Right)89°/89°/89°/89° (Type)(CR≥10)
Response Time30ms
LCD Panel Lifespan (Hours)60,000(Hour.)
Field Frequency60Hertz
Audio parametersAudio systemStereo
Speaker size≈ 99 x 45 x 20 mm
Impedance8 Ω
Power2 x 5 Watt
Loudness> 80 Decibel
Interface4-pin connector
Internal computer configuration
(Choose one of two)
CPUIntel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHzIntel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics CardIntegrated Graphics Card Intel® HD 4600Integrated Graphics Card Intel® HD 530
RAM4GB8GB
Storage Memory Capacity128GB256GB
OSWin10 or win11 OptionalWin10 or win11 Optional
Wi-Fi Built-inSpeed 150Mbps 802.11n wifi IntegratedSpeed 150Mbps 802.11n wifi Integrated
Media FormatVideo Formatwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio FormatMP3, WMA
Photo FormatBMP, JPEG, PNG, GIF etc.
Onboard InterfaceNetwork portRJ45 X 1, 10M/100M Adjustable Ethernet
HDMI1
USB4
PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
Maximum Power Loss≤ 30 Watt
Standby Mode Power Loss< 1 Watt
FeaturesOperating Temperature0℃ ~ 50℃
Storage TemperatureBelow 10℃ ~ +60℃
Package SizeDevice Dimensions403.9 X 263.9X 56.7mm.
Net Weight5 Kilogram
Package Size47 X 33 X 17Centimeter
Gross Package Weight per Unit5.5 Kilogram


For security systems, the 15.6-inch monitor proves invaluable for surveillance and monitoring purposes. Whether placed in a centralized security control room or used in outdoor kiosks, this high-resolution display ensures that live video feeds from surveillance cameras are crystal clear. Its wide viewing angles and high contrast ratio enhance visibility from various vantage points, helping security personnel quickly spot potential threats or breaches. The monitor's stereo audio system provides an added layer of functionality, delivering auditory cues alongside the visual alerts for more effective real-time monitoring. Additionally, its energy-efficient design makes it suitable for continuous operation, an essential feature for 24/7 security setups.

15.6-Inch Slim Windows Display for Factory Dashboards and Security Systems 015.6-Inch Slim Windows Display for Factory Dashboards and Security Systems 115.6-Inch Slim Windows Display for Factory Dashboards and Security Systems 215.6-Inch Slim Windows Display for Factory Dashboards and Security Systems 315.6-Inch Slim Windows Display for Factory Dashboards and Security Systems 4
15.6-Inch Slim Windows Display for Factory Dashboards and Security Systems 5
The 15.6-inch display is also an excellent choice for interactive kiosks and customer service applications within industries such as retail, logistics, and transportation. Its user-friendly interface allows for the display of dynamic content, such as product catalogs, real-time shipment tracking, or digital signage. The slim profile and lightweight build make it easy to integrate into self-service terminals or point-of-sale systems. With the added benefits of Windows OS, businesses can run custom software, manage databases, and access cloud services directly from the display, enhancing the user experience. Furthermore, its long lifespan and low power consumption ensure it remains a reliable and cost-effective option for environments requiring constant use, such as airports, shopping malls, and information desks.
