17-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring

17-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring

  • 17-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring
  • 17-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring
17-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-E170WPS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight cases are optional
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 17.0 Inch Aspect Ratio: 16:9
Brightness: 400 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An

17-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring

The 17-inch Windows display is a versatile solution tailored for industrial control systems, offering crisp visuals and seamless performance. With its high contrast ratio of 1200:1 and wide viewing angles, it provides clear and detailed monitoring of machinery, production lines, or automated systems. Its compact yet efficient design makes it ideal for mounting in factories or assembly areas where space is at a premium. The screen’s 1280x1024 resolution ensures high-quality image reproduction, allowing operators to monitor real-time data with accuracy. Its built-in connectivity options such as Ethernet and HDMI provide easy integration with other devices, making it an essential tool for smart manufacturing, production oversight, and equipment diagnostics.

LCD Panel ParametersScreen Size17 Inch
Display Area337.92 mm.(Height) X 270.34(Width)mm.
Aspect Ratio16 : 9
LCD Typea-Si TFT-LCD Monitor
Maximum Resolution1280 X 1024
Display Color16.7M , 72% NTSC
Brightness250cd/m²
Contrast Ratio1200 : 1
Viewing Angle (Up/Down/Left/Right)89°/89°/89°/89° (Type)(CR≥10)
Response Time20ms
LCD Panel Lifespan (Hours)60,000(Hour.)
Field Frequency60Hertz
Audio parametersAudio systemStereo
Speaker size≈ 99 x 45 x 20 mm
Impedance8 Ohm
Power2 x 5 Watt
Loudness> 80 Decibel
Interface4-pin connector
Internal computer configuration
(Choose one of two)
CPUIntel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHzIntel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics CardIntegrated Graphics Card Intel® HD 4600Integrated Graphics Card Intel® HD 530
RAM4GB8GB
Storage Memory Capacity128GB256GB
OSWin10 or win11 OptionalWin10 or win11 Optional
Wi-Fi Built-inSpeed 150Mbps 802.11n wifi IntegratedSpeed 150Mbps 802.11n wifi Integrated
Media FormatVideo Formatwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio FormatMP3, WMA
Photo FormatBMP, JPEG, PNG, GIF etc.
Onboard InterfaceNetwork portRJ45 X 1, 10M/100M Adjustable Ethernet
HDMI1
USB4
PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
Maximum Power Loss≤ 30 Watt
Standby Mode Power Loss< 1 Watt
FeaturesOperating Temperature0℃ ~ 50℃
Storage TemperatureBelow 10℃ ~ +60℃
Package SizeDevice Dimensions400.6 X 338.6 X 50 mm.
Net Weight5.5 Kilogram
Package Size48 X 39 X 15 Centimeter
Gross Package Weight per Unit6 Kilogram


In the realm of security monitoring, this 17-inch display excels as an integral component of surveillance systems. Offering clear image quality at a brightness of 250cd/m², it ensures high visibility even in well-lit or outdoor environments. The integrated stereo speakers add an extra layer of functionality, enabling audio alerts alongside visual monitoring. Whether installed in control rooms, command centers, or security stations, this display is designed to handle continuous operation with a lifespan of 60,000 hours, ensuring long-term reliability. It can manage video feeds from multiple cameras, providing an effective interface for real-time security surveillance and incident tracking, crucial for public safety, facility management, and traffic monitoring.

17-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring 017-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring 117-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring 217-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring 317-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring 417-Inch Versatile Windows Screen for Industrial Equipment and Security Monitoring 5
Beyond industrial and security use, the 17-inch display finds its place in interactive kiosks and digital signage. In retail, transportation hubs, or hospitality environments, this screen delivers vibrant media displays for advertisements, product promotions, or wayfinding systems. The Wi-Fi connectivity makes it an ideal choice for dynamic content updates, while its video and image format support ensures compatibility with various media types. Its versatile design allows for both horizontal and vertical installations, making it adaptable to different display setups. Whether used for customer engagement, information dissemination, or public communication, this screen enhances user interaction by providing clear, high-quality visual content across a variety of settings.
