19-Inch Windows Display for Transportation Systems and Access Control

19-Inch Windows Display for Transportation Systems and Access Control

  • 19-Inch Windows Display for Transportation Systems and Access Control
  • 19-Inch Windows Display for Transportation Systems and Access Control
19-Inch Windows Display for Transportation Systems and Access Control
Product Details:
Place of Origin: Guangdong, China
Brand Name: ZXTLCD
Certification: CE/Rohs/FCC
Model Number: ZXTLCD-E190WPS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden case, carton, flight cases are optional
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Screen Size: 19.0 Inch Aspect Ratio: 16:9
Brightness: 400 Cd/m² Install Type: Embedded, Open-frame, Wall-mounted, Floor-standing
Suitable Environment: Outdoor; Indoor Applications: Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An

19-Inch Windows Display for Transportation Systems and Access Control

The 19-inch Windows display is a powerful solution for transportation systems, enhancing passenger experience in bus terminals, train stations, and airports. With its sharp 1280x1024 resolution, this display ensures that schedules, announcements, and digital maps are presented clearly and accurately. The wide viewing angles (89° in all directions) make it ideal for high-traffic areas where passengers are spread across various distances. It also serves as an excellent tool for real-time updates on arrivals, departures, and delays. Built with durability in mind, the monitor can withstand the rigors of transportation environments while providing clear visibility and energy efficiency through low power consumption.

LCD Panel ParametersScreen Size19 Inch
Display Area376.32 mm.(Height) X 301.06(Width)mm.
Aspect Ratio4 : 3
LCD Typea-Si TFT-LCD Monitor
Maximum Resolution1280 X 1024
Display Color16.7m , 73% NTSC
Brightness250cd/m²
Contrast Ratio1000 : 1
Viewing Angle (Up/Down/Left/Right)89°/89°/89°/89° (Type)(CR≥10)
Response Time14Miss
LCD Panel Lifespan (Hours)60,000(Hour.)
Field Frequency60Hertz
Audio parametersAudio systemStereo
Speaker size≈ 99 x 45 x 20 mm
Impedance8 Ohm
Power2 x 5 Watt
Loudness> 80 Decibel
Interface4-pin connector
Internal computer configuration
(Choose one of two)
CPUIntel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHzIntel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics CardIntegrated Graphics Card Intel® HD 4600Integrated Graphics Card Intel® HD 530
RAM4GB8GB
Storage Memory Capacity128GB256GB
OSWin10 or win11 OptionalWin10 or win11 Optional
Wi-Fi Built-inSpeed 150Mbps 802.11n wifi IntegratedSpeed 150Mbps 802.11n wifi Integrated
Media FormatVideo Formatwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio FormatMP3, WMA
Photo FormatBMP, JPEG, PNG, GIF etc.
Onboard InterfaceNetwork portRJ45 X 1, 10M/100M Adjustable Ethernet
HDMI1
USB4
PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
Maximum Power Loss≤ 30 Watt
Standby Mode Power Loss< 1 Watt
FeaturesOperating Temperature0℃ ~ 50℃
Storage TemperatureBelow 10℃ ~ +60℃
Package SizeDevice Dimensions436.5 X 364.5 X 50 mm.
Net Weight6.5 Kilogram
Package Size52 X 44 X 15 Centimeter
Gross Package Weight per Unit7 Kilogram


This versatile display excels in access control systems where it can be seamlessly integrated into security kiosks and check-in points. Whether used for secure building entries, gated communities, or restricted areas, it offers a reliable solution for displaying important visitor information, security protocols, or live surveillance feeds. The integrated audio system ensures that the accompanying sound is clear, whether for alert notifications or interactive communication. With Wi-Fi connectivity and options for cloud-based management, this display can streamline security operations and provide real-time updates to staff or security personnel. Its compact and sturdy design makes it ideal for both indoor and outdoor installations.

19-Inch Windows Display for Transportation Systems and Access Control 019-Inch Windows Display for Transportation Systems and Access Control 119-Inch Windows Display for Transportation Systems and Access Control 219-Inch Windows Display for Transportation Systems and Access Control 319-Inch Windows Display for Transportation Systems and Access Control 419-Inch Windows Display for Transportation Systems and Access Control 5
Moreover, the 19-inch monitor proves to be an exceptional tool for advertising and digital signage in high-traffic commercial environments such as malls, retail stores, and exhibition spaces. It allows businesses to engage customers with dynamic content, such as promotions, event schedules, or product information. The high brightness ensures that the display is visible even in well-lit environments, while the variety of supported media formats (video, audio, and images) ensures that content is engaging and versatile. Its energy-efficient design and low power consumption make it ideal for continuous operation, making it an asset for businesses aiming to attract and inform potential customers in public spaces. The ease of integration with various media formats makes it an all-in-one solution for businesses looking to upgrade their advertising and information systems.
