Place of Origin: | Guangdong, China |
Brand Name: | ZXTLCD |
Certification: | CE/Rohs/FCC |
Model Number: | ZXTLCD-E170WPSWFS |
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiable |
Packaging Details: | wooden case, carton, flight cases are optional |
Delivery Time: | 3-5 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 2000 pcs per month |
Screen Size: | 17.0 Inch | Aspect Ratio: | 16:9 |
---|---|---|---|
Brightness: | 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 17-inch integrated monitor is a perfect choice for industrial automation and logistics operations, offering a seamless display experience in environments that demand precision and reliability. With a 1280 x 1024 resolution and an impressive 1200:1 contrast ratio, the screen delivers vibrant and clear visuals, ensuring that critical data is always easy to read, whether for controlling machinery or monitoring automated processes. Its versatility is further enhanced by built-in Wi-Fi and multiple ports, including USB and HDMI, allowing it to integrate seamlessly into existing automation systems. This makes it an excellent solution for use in control panels, warehouse systems, and manufacturing dashboards, where the monitor needs to handle a wide variety of tasks simultaneously.
LCD Panel Parameters | Screen Size | 17 Inch | ||
Display Area | 337.92 mm.(Height) X 270.34(Width)mm. | |||
Aspect Ratio | 16 : 9 | |||
LCD Type | a-Si TFT-LCD Monitor | |||
Maximum Resolution | 1280 X 1024 | |||
Display Color | 16.7M , 72% NTSC | |||
Brightness | 250cd/m² | |||
Contrast Ratio | 1200 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
Response Time | 20ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 60Hertz | |||
Audio parameters | Audio system | Stereo | ||
Speaker size | ≈ 99 x 45 x 20 mm | |||
Impedance | 8 Ohm | |||
Power | 2 x 5 Watt | |||
Loudness | > 80 Decibel | |||
Interface | 4-pin connector | |||
Internal computer configuration (Choose one of two) | CPU | Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz | Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz | |
Graphics Card | Integrated Graphics Card Intel® HD 4600 | Integrated Graphics Card Intel® HD 530 | ||
RAM | 4GB | 8GB | ||
Storage Memory Capacity | 128GB | 256GB | ||
OS | Win10 or win11 Optional | Win10 or win11 Optional | ||
Wi-Fi Built-in | Speed 150Mbps 802.11n wifi Integrated | Speed 150Mbps 802.11n wifi Integrated | ||
Media Format | Video Format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. | ||
Audio Format | MP3, WMA | |||
Photo Format | BMP, JPEG, PNG, GIF etc. | |||
Onboard Interface | Network port | RJ45 X 1, 10M/100M Adjustable Ethernet | ||
HDMI | 1 | |||
USB | 4 | |||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 30 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 400.6 X 338.6 X 56.7 mm. | ||
Net Weight | 5.5 Kilogram | |||
Package Size | 48 X 39 X 17 Centimeter | |||
Gross Package Weight per Unit | 6 Kilogram |
In logistics and inventory management, the 17-inch display shines as an indispensable tool for tracking stock, monitoring shipments, and improving operational efficiency. Its compact size makes it ideal for integration into warehouse control stations, where real-time tracking of goods and barcode scanning systems are essential. With its brightness of 250cd/m², the screen ensures clear visibility even in less-than-ideal lighting conditions. The built-in speakers and the ability to handle multiple media formats make it a powerful tool for dispatch teams, providing both visual and audio alerts during package handling, ensuring quick responses in busy logistics hubs or distribution centers.
Beyond its use in industrial and logistics operations, the 17-inch Windows-based display is highly effective in security systems and surveillance monitoring. Security stations can integrate this unit into video monitoring setups, offering clear, high-quality visuals for real-time monitoring of live feeds or automated alarm systems. The wide viewing angles and excellent contrast ratio ensure that operators can always get a clear picture, even when observing from varying angles. Moreover, with its low power consumption and long lifespan, it is an ideal solution for environments requiring continuous 24/7 operation, like security control rooms, critical infrastructure monitoring, and traffic management centers.
