Place of Origin: | Guangdong, China |
Brand Name: | ZXTLCD |
Certification: | CE/Rohs/FCC |
Model Number: | ZXTLCD-E185WPSWFS |
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiable |
Packaging Details: | wooden case, carton, flight cases are optional |
Delivery Time: | 3-5 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 2000 pcs per month |
Screen Size: | 18.5 Inch | Aspect Ratio: | 16:9 |
---|---|---|---|
Brightness: | 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 18.5-inch Windows-based monitor is a powerful and reliable solution for transportation control panels and vehicle monitoring systems. Offering high-definition visuals with a 1920 x 1080 resolution and 1200:1 contrast ratio, this screen ensures clear and detailed images, making it an essential tool for use in fleet management systems, bus terminals, and railway stations. The bright display, coupled with wide viewing angles, makes it perfect for operators who need to view real-time data, such as vehicle location, scheduling, and status updates from various positions. Whether mounted in a control center or used in onboard transport systems, this monitor enhances efficiency and safety by providing seamless integration with navigation, communication, and surveillance systems.
LCD Panel Parameters | Screen Size | 18.5 Inch | ||
Display Area | 409.8 mm.(Height) X 230.4(Width)mm. | |||
Aspect Ratio | 16 : 9 | |||
LCD Type | a-Si TFT-LCD Monitor | |||
Maximum Resolution | 1920 X 1080 | |||
Display Color | 16.7m , 72% NTSC | |||
Brightness | 250cd/m² | |||
Contrast Ratio | 1200 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
Response Time | 14ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 60Hertz | |||
Audio parameters | Audio system | Stereo | ||
Speaker size | ≈ 99 x 45 x 20 mm | |||
Impedance | 8 Ohm | |||
Power | 2 x 5 Watt | |||
Loudness | > 80 Decibel | |||
Interface | 4-pin connector | |||
Internal computer configuration (Choose one of two) | CPU | Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz | Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz | |
Graphics Card | Integrated Graphics Card Intel® HD 4600 | Integrated Graphics Card Intel® HD 530 | ||
RAM | 4GB | 8GB | ||
Storage Memory Capacity | 128GB | 256GB | ||
OS | Win10 or win11 Optional | Win10 or win11 Optional | ||
Wi-Fi Built-in | Speed 150Mbps 802.11n wifi Integrated | Speed 150Mbps 802.11n wifi Integrated | ||
Media Format | Video Format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. | ||
Audio Format | MP3, WMA | |||
Photo Format | BMP, JPEG, PNG, GIF etc. | |||
Onboard Interface | Network port | RJ45 X 1, 10M/100M Adjustable Ethernet | ||
HDMI | 1 | |||
USB | 4 | |||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 30 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 470.9 X 294.9 X 56.7mm | ||
Net Weight | 6.5 Kilogram | |||
Package Size | 55 X 38 X 15Centimeter | |||
Gross Package Weight per Unit | 7 Kilogram |
In industrial settings, the 18.5-inch monitor is ideal for managing machinery controls, safety monitoring systems, and production line management. Its responsive touch interface and Windows operating system offer a user-friendly environment for real-time data visualization and interaction, which is crucial in environments like warehouses, factories, and manufacturing plants. Operators can easily monitor machinery status, adjust production settings, and access diagnostic tools, all within the same system. The built-in Intel i5 processor and Wi-Fi connectivity ensure smooth performance, making this monitor suitable for both on-premise installations and remote equipment control.
Additionally, this monitor serves as an excellent choice for interactive kiosks, smart signage, and public display panels. Thanks to its high brightness and vivid color output, it stands out in high-traffic areas like airports, shopping malls, and public transportation hubs. Whether used for ticketing kiosks, wayfinding displays, or advertising, this screen delivers a crisp and reliable display that can be easily updated with content via its USB ports or HDMI interface. With its long lifespan and low power consumption, it’s a cost-effective option for environments that require continuous operation while maintaining low maintenance costs.
