Place of Origin: | Guangdong, China |
Brand Name: | ZXTLCD |
Certification: | CE/Rohs/FCC |
Model Number: | ZXTLCD-E190WPSWFS |
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiable |
Packaging Details: | wooden case, carton, flight cases are optional |
Delivery Time: | 3-5 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 2000 pcs per month |
Screen Size: | 19.0 Inch | Aspect Ratio: | 16:9 |
---|---|---|---|
Brightness: | 400 Cd/m² | Install Type: | Embedded, Open-frame, Wall-mounted, Floor-standing |
Suitable Environment: | Outdoor; Indoor | Applications: | Industrial Control, Medical Equipment, Automotive Systems, Various Self-service Terminals (new Retail Vending Machines/financial Terminals/information Kiosks/parcel Lockers/storage Lockers/garbage Recycling Cabinets/charging Stations, Etc.), Hospitality An |
The 19-inch precision display is an excellent choice for access control systems in secure environments like corporate offices, banks, and government institutions. Its crisp 1280x1024 resolution ensures clear visual feedback of real-time security information, including personnel identification and visitor tracking. The display can be integrated with biometric systems or used in keycard entry points, providing a seamless interaction for authorized users. With its wide viewing angles and high contrast ratio, this monitor is designed to offer enhanced visibility for security personnel, ensuring that the information is accessible and easy to interpret in various lighting conditions. The reliable Intel processors and Wi-Fi connectivity further improve integration with cloud-based security platforms, giving real-time updates to maintain optimal security protocols.
LCD Panel Parameters | Screen Size | 19 Inch | ||
Display Area | 376.32 mm.(Height) X 301.06(Width)mm. | |||
Aspect Ratio | 4 : 3 | |||
LCD Type | a-Si TFT-LCD Monitor | |||
Maximum Resolution | 1280 X 1024 | |||
Display Color | 16.7m , 73% NTSC | |||
Brightness | 250cd/m² | |||
Contrast Ratio | 1000 : 1 | |||
Viewing Angle (Up/Down/Left/Right) | 89°/89°/89°/89° (Type)(CR≥10) | |||
Response Time | 14ms | |||
LCD Panel Lifespan (Hours) | 60,000(Hour.) | |||
Field Frequency | 60Hertz | |||
Audio parameters | Audio system | Stereo | ||
Speaker size | ≈ 99 x 45 x 20 mm | |||
Impedance | 8 Ohm | |||
Power | 2 x 5 Watt | |||
Loudness | > 80 Decibel | |||
Interface | 4-pin connector | |||
Internal computer configuration (Choose one of two) |
CPU | Intel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz | Intel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz | |
Graphics Card | Integrated Graphics Card Intel® HD 4600 | Integrated Graphics Card Intel® HD 530 | ||
RAM | 4GB | 8GB | ||
Storage Memory Capacity | 128GB | 256GB | ||
OS | Win10 or win11 Optional | Win10 or win11 Optional | ||
Wi-Fi Built-in | Speed 150Mbps 802.11n wifi Integrated | Speed 150Mbps 802.11n wifi Integrated | ||
Media Format | Video Format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. | ||
Audio Format | MP3, WMA | |||
Photo Format | BMP, JPEG, PNG, GIF etc. | |||
Onboard Interface | Network port | RJ45 X 1, 10M/100M Adjustable Ethernet | ||
HDMI | 1 | |||
USB | 4 | |||
Power | Power Supply | Alternating Current 100V~240V, 50/60Hz | ||
Maximum Power Loss | ≤ 30 Watt | |||
Standby Mode Power Loss | < 1 Watt | |||
Features | Operating Temperature | 0℃ ~ 50℃ | ||
Storage Temperature | Below 10℃ ~ +60℃ | |||
Package Size | Device Dimensions | 436.5 X 364.5 X 56.7 mm. | ||
Net Weight | 6.5 Kilogram | |||
Package Size | 52 X 44 X 15 Centimeter | |||
Gross Package Weight per Unit | 7 Kilogram |
In medical environments, this monitor serves as a critical tool for applications like patient monitoring and diagnostic imaging. Whether used in ICU rooms for tracking vital signs or in radiology departments to view high-resolution X-rays and CT scans, its sharp display resolution and accurate color reproduction ensure medical professionals can make informed decisions based on clear data. The long lifespan and low power consumption make it ideal for continuous use in settings that demand reliability and efficiency. Additionally, with Wi-Fi capabilities, it integrates seamlessly with hospital record-keeping systems and health management software, enabling instant access to patient data from various departments. Its high brightness and contrast ratio ensure visibility even in challenging lighting conditions, ensuring smooth patient care and monitoring.
This 19-inch display also excels in various interactive applications such as self-service kiosks, digital signage, and interactive wayfinding systems in places like malls, airports, and public transport stations. Offering a sturdy build with multiple input options, including USB, HDMI, and Ethernet, it is well-suited for both indoor and outdoor applications where real-time information is essential. In ticketing machines or airport check-ins, the display allows users to quickly access information, while interactive touch applications enable self-registration or check-ins, offering a seamless experience. The versatile display can also be used for advertising purposes, displaying high-quality visual content for businesses looking to engage their customers in high-traffic areas. Its energy-efficient design ensures low operating costs, making it a practical choice for both businesses and public organizations.
